Chapter 6 Troubleshooting the Control Plane Ethernet Network
Troubleshooting Booting the System Control Plane Ethernet
Network
To verify and troubleshoot booting the Cisco CRS-1 system control plane Ethernet network, perform the
following procedures.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
DETAILED STEPS
Command or Action
Step 1
show platform
Example:
RP/0/RP0/CPU0:router# show platform
Step 2
admin debug shelfmgr boot
Example:
RP/0/RP0/CPU0:router# admin debug shelfmgr boot
OL-21483-02
show platform
admin debug shelfmgr boot
show controllers backplane ethernet clients all location node-id
show controllers backplane ethernet clients 13 statistics location node-id
show controllers switch {0 | 1} statistics location node-id
Place the designated shelf controller (DSC) in ROM Monitor (ROMMON) mode:
a. admin
config register 0x0
b.
exit
c.
reload
d.
show_bcm_links (Cisco CRS-1 Multishelf System only)
Exit ROMMON mode:
confreg 0x102
a.
reset
b.
Contact Cisco Technical Support if the problem is not resolved.

Troubleshooting Booting the System Control Plane Ethernet Network

Purpose
Displays information about the status of cards and modules
installed in the router.
Verify that the expected nodes display IOS XR RUN under
the State column of the command output.
If no output is displayed, the shelfmgr is not receiving boot
requests.
Cisco IOS XR Troubleshooting Guide for the Cisco CRS-1 Router
6-149
