Chapter 3
Recommended 208 VAC
Power Configuration
for the LC 2000r
Uninter-
ruptible
Power
Supply
Captive
L6-20P
Cord
Cable Orderable for
16-Amp PDU,
E7801A L6-20P to
IEC 320 C19, 2.5 m
(Other Configurations Possible)

230/240V PDU Rack Power Configurations

Configurations for the 230/240 VAC, PDU options are shown in the text below,
Table , and Figure
3-3
230/240 VAC Power Configuration
In a country with a 230/240 VAC power system, the wide range (200/240 V) PDU
model E7671A is required. If you are using a UPS, attach the C-19 end of the
42
Procedure for Connecting and Routing Cables to the LC 2000r
16-Amp Power
Distribution
Unit, E7671A
Figure 3-4. 208 VAC PDU Configuration
.
3-5
HP NetServer
LC 2000r
Rack Mass
Storage Unit
Jumper Cable
Supplied with
NetServer
Jumper Cables
Supplied with
Mass Storage
Units
