Table 3-2. 208 VAC Components
1
Component
208 VAC
PDU
HP NetServer D8515A, 533 MHz, 128 MB
LC 2000r D8520A, 600 MHz, 128 MB
D8525A, 667 MHz, 128 MB
HP NetServer Rack Storage/12 is D5989A
Mass Storage Rack Storage/12FC is D5991A
Unit
HP Console
Switch
Note 1 More ratings are listed in Table 2-8. For a full list of power ratings, see the rack
configuration utilities (for instance, Rack Assistant) on the HP Web Site.
Note 2 Indicated current ratings are for use in selecting PDU and UPS components and
may not reflect actual measured amounts.
Description of the Recommended 208 VAC Configuration
Figure 3-4 shows a UPS connected to the power mains through a captive cord
terminated with an L6-20P plug. The UPS has five receptacles for use in the rack:
two (on the right rear) NEMA 5-15 providing 110 VAC, two L6-20R, and one
L6-30R, providing 208VAC. The E7671A PDU connects to the UPS via a
detachable cord with an L6-20P plug. This cord connects to the PDU with an IEC
320 C-19 plug. The 208 VAC PDU has two IEC 320, C-19 and six IEC 320, C-13
receptacles. A second PDU (E7670A) is available, which can be daisy-chained to
the 16-amp unit, providing ten more C-13 receptacles.
Procedure for Connecting and Routing Cables to the LC 2000r
Model
E7671A or E7672A
J1497B
Power Power Current
(VA) (W)
(A)
N/A N/A max 16
516 506 2.5
522 512 2.6
42 29 0.2
41
2
