IBM 3270 Display Emulation
Copying Screen
Data to a Function
Key
170 Notice Board Facility
diagonally-opposite corners of the selected area by pressing the
Return key.
Press F13 to copy the selected area. The copied area (i.e. the tar-
4
get) will be highlighted in red.
Use the cursor keys to move the red target area to the required
5
position on the display. You can also use the Jump key to move
the target area to the host screen or Notice Board.
Press Enter on the numeric keypad to save the copied area at the
6
current position on the display.
The following procedure describes how to copy screen data to a
function key. Note that the
options that determine whether this facility is enabled and whether
all screen data in the selected area is copied, or only data in user
entry fields. See "Notice Board Settings" on page 181 for details.
Position the text cursor at the start of the area to be copied.
1
Press the Copy key to start the Copy function. Note that the
2
status line will display the key functions available.
Use the cursor keys to move the text cursor to the diagonally-
3
opposite corner of the display area to be copied. The currently
selected area will be highlighted in green. Note that you can
toggle the position of the text cursor between the two
diagonally-opposite corners of the selected area by pressing the
Return key.
Press F14 to copy the selected area.
4
Press the function key required to store the copied data.
5
Press Enter on the numeric keypad to store the copied data in
6
the chosen function key.
3270 Display Settings
dialog has several
