- Page 1 Hardware Reference Guide HP t5145/t5540/t5545/t5630 Thin Clients...
- Page 2 Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. This document contains proprietary information that is protected by copyright.
-
Page 3: About This Book
About This Book WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily harm or loss of life. CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information. - Page 4 About This Book...
-
Page 5: Table Of Contents
Table of contents 1 Product Features Standard Features ... 1 Thin Client Management Solutions ... 2 Front Panel Components ... 3 Top Components ... 4 Rear Panel Components ... 5 Installing the Rubber Feet ... 5 Installing the Stand ... 6 Removing the Stand ... - Page 6 Appendix C Mounting the Thin Client HP Quick Release ... 22 Supported Mounting Options ... 24 Non-supported Mounting Option ... 26 Appendix D Thin Client Operation Routine Thin Client Care ... 27 Supported Orientations ... 27 Non-supported Orientation ... 29 Appendix E Electrostatic Discharge Preventing Electrostatic Damage ...
-
Page 7: Product Features
Standard Features Thank you for purchasing an HP thin client. We hope you have years of use from our thin clients. Our goal is to provide you with award-winning clients that are easy to deploy and manage with the power and reliability you expect. -
Page 8: Thin Client Management Solutions
HP ThinState Tools are a set of handy utilities that allow you to copy settings and software images from one thin client to another using a USB drive key. HP ThinState tools complement other management solutions and are included with HP thin client operating systems. -
Page 9: Front Panel Components
Front panel components Secure USB compartment Power button Flash activity LED Line-in (microphone) connector http://www.hp.com and search for your specific thin client model to find the model- Line-out (headphone) audio connector Universal serial bus (USB) connectors (2) Power LED Front Panel Components... -
Page 10: Top Components
Top components, external view Secure USB compartment Cable lock slot Figure 1-3 Top components, internal view Secure USB compartment ports (2) Cable lock slot Chapter 1 Product Features http://www.hp.com and search for your specific thin client model to find the model-... -
Page 11: Rear Panel Components
If your unit does not have VESA mounting holes, you will need to obtain the optional side panels with VESA mounting holes. Remove the feet from their backing. http://www.hp.com and search for your specific thin client model to find the model- VGA connector... -
Page 12: Installing The Stand
Align the feet with their holes and press them in securely. Figure 1-5 Installing the rubber feet Installing the Stand If your unit does not have VESA mounting holes, you will need to use the thin client in a vertical orientation and install the stand for stability. -
Page 13: Removing The Stand
Removing the Stand To remove the stand: Turn unit upside down. Lift the tab (1), then slide the stand toward the front of the thin client and pull it up to remove it from the unit (2). Figure 1-7 Removing the stand Removing the Stand... -
Page 14: Using The Keyboard
Using the Keyboard Figure 1-8 Keyboard features Caps Lock Scroll Lock Num Lock Ctrl Windows Logo Key Application key Editing keys Available in select geographic regions. Applies to XPe thin clients only. Chapter 1 Product Features Activates/deactivates the Caps Lock feature. Activates/deactivates the Scroll Lock feature. -
Page 15: Windows Logo Key
Windows Logo Key Use the Windows Logo Key in combination with other keys to perform certain functions available in Windows operating systems. Windows Logo Key + Windows Logo Key + Windows Logo Key + Windows Logo Key + Ctrl Windows Logo Key + Windows Logo Key + Shift Windows Logo Key +... -
Page 16: Serial Number Location
Serial Number Location Every thin client includes a unique serial number located as shown in the following illustration. Have this number available when contacting HP customer service for assistance. Figure 1-9 Serial number location Chapter 1 Product Features... -
Page 17: Hardware Changes
Hardware Changes General Hardware Installation Sequence To ensure the proper installation thin client hardware components: Back up any data, if necessary. If the thin client is powered on: Turn off the computer properly through the operating system, then turn off any external devices. -
Page 18: Removing And Replacing The Secure Usb Compartment Cover
Turn on the monitor, the thin client, and any devices you want to test. Load any necessary drivers. NOTE: You can download select hardware drivers from HP. Go to for your specific thin client model. Reconfigure the thin client, if necessary. -
Page 19: Replacing The Secure Usb Compartment Cover
Push the compartment cover about .6 cm (1/4 inch) toward the front of the unit (2) and lift it off the unit (3). Figure 2-1 Removing the secure USB compartment cover Replacing the Secure USB Compartment Cover To replace the secure compartment cover: Place the cover on top of the unit so it is offset about 0.6 cm (1/4 inch) toward the front of the unit, allowing the tabs on the cover to align with the slots on the chassis (1). -
Page 20: Removing And Replacing The Side Access Panel And Metal Side Cover
Removing and Replacing the Side Access Panel and Metal Side Cover Removing the Side Access Panel and Metal Side Cover WARNING! Before removing the side access panel, ensure that the thin client is turned off and the power cord is disconnected from the electrical outlet. To remove the access panel: Remove the secure compartment cover (1). -
Page 21: Replacing The Metal Side Cover And Side Access Panel
Lift the metal side cover, rear side first, off the unit (2). Figure 2-4 Removing the metal side cover Replacing the Metal Side Cover and Side Access Panel To replace the metal side cover: Slip the front edge of the metal side cover under the lip on the chassis and lower the cover until it snaps into place (1). -
Page 22: Installing Thin Client Options
Installing Thin Client Options Various options can be installed on the thin client: ● Installing the USB Device on page 16 ● Removing and Replacing the Battery on page 17 Installing the USB Device Before beginning the replacement process, review on page 11 for procedures you should follow before and after installing or replacing hardware. -
Page 23: Removing And Replacing The Battery
Slide one edge of the battery into the slot and push down until the guard snaps over the edge of the battery . HP encourages customers to recycle used electronic hardware, HP original print cartridges, and rechargeable batteries. For more information about recycling programs, go to search for “recycle”. -
Page 24: External Drives
For more information about available options, visit the HP Web your specific thin client model. Chapter 2 Hardware Changes and search for your specific thin client model, or refer to the sitehttp://www.hp.com... -
Page 25: Appendix A Specifications
50° to 104° F -30° to 60° C -22° to 140° F ** The operating temperature range when the thin client is attached to a flat panel using the HP Quick Release is 50° to 95° F (10° to 35° C). 10–90% 10–90% 5–95%... - Page 26 Table A-1 HP t5145/t5540/t5545/t5630 Thin Client (continued) Rated Line Frequency Power Output (maximum) Rated Output Current (maximum) Output Voltage Appendix A Specifications 50–60 Hz 50–60 Hz 50 W 50 W 4.16 A 4.16 A +12 V DC +12 V DC...
-
Page 27: Appendix B Security Provisions
Securing the Thin Client These thin clients are designed to accept a security cable lock. This cable lock prevents unauthorized removal of the thin client, as well as locking the secure compartment. To order this option, visit the HP Web site at http://www.hp.com... -
Page 28: Appendix C Mounting The Thin Client
HP Quick Release If your thin client does not have VESA mounting holes, you must obtain and install the optional side panels with VESA mounting holes and HP Quick Release. To order, visit the HP Web site at http://www.hp.com and search for your specific thin client model. - Page 29 To use the HP Quick Release with a VESA-configured thin client: Using four 10 mm screws included in the mounting device kit, attach one side of the HP Quick Release to the thin client as shown in the following illustration.
-
Page 30: Supported Mounting Options
Figure C-4 Connecting the thin client NOTE: When attached, the HP Quick Release automatically locks in position. You only need to slide the lever to one side to remove the thin client. CAUTION: To ensure proper function of the HP Quick Release and a secure connection of all components, make sure both the release lever on one side of the mounting device and the rounded opening on the other side face upward. - Page 31 Thin client mounted on back of monitor stand ● You can mount the thin client on a wall. Figure C-7 Thin client mounted on wall ● You can mount the thin client under a desk. Figure C-8 Thin client mounted under desk HP Quick Release...
-
Page 32: Non-Supported Mounting Option
Non-supported Mounting Option CAUTION: Mounting a thin client in an non-supported manner could result in failure of the HP Quick Release and damage to the thin client and/or other equipment. Do not mount the thin client on a flat panel monitor stand, between the panel and the stand. -
Page 33: Appendix D Thin Client Operation
Supported Orientations HP supports the following orientations for the thin client. CAUTION: You must adhere to HP-supported orientations to ensure your thin clients function properly. ● You can place the thin client vertically using the supplied stand. - Page 34 NOTE: If your unit does not have VESA mounting holes, you will need to obtain the optional side panels with VESA mounting holes. Figure D-2 Horizontal orientation ● You can lay the thin client under a monitor stand with at least one inch of clearance. Figure D-3 Under monitor stand Appendix D Thin Client Operation...
-
Page 35: Non-Supported Orientation
Non-supported Orientation HP does not support the following orientation for the thin client. CAUTION: Non-supported placement of thin clients could result in operation failure and/or damage to the devices. CAUTION: Thin clients require proper ventilation to maintain operating temperature. Do not block the vents. -
Page 36: Appendix E Electrostatic Discharge
Use conductive field service tools. ● Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, contact an HP authorized dealer, reseller, or service provider. NOTE: For more information about static electricity, contact an HP authorized dealer, reseller, or service provider. -
Page 37: Appendix F Shipping Information
For environmental nonoperating ranges, see Important Service Repair Information In all cases, remove and safeguard all external options before returning the thin client to HP for repair or exchange. In countries that support customer mail-in repair by returning the same unit to the customer, HP makes every effort to return the repaired unit with the same internal memory and flash modules that were sent. -
Page 38: Index
