Page 1 ® TeemTalk for Unix User's Guide...
Page 2 Neoware UK Ltd Host Access Business Unit The Stables, Cosgrove Milton Keynes MK19 7JJ Tel: +44 (0) 1908 267111 Fax: +44 (0) 1908 267112 Email: teem-info@neoware.com Neoware Systems, Inc. 400 Feheley Drive King of Prussia, PA 19406 Tel: +1.610.277.8300 Fax: +1.610.275.5739 FRANCE Neoware Systems, Inc.
Page 3: Software Support
TeemTalk Software Support Telephone: +1.610.277.8300 Web: http://www.neoware.com/support/ Software Version 5.0.1 October 2004 Part number: TT5DM-5.0.1 Neoware UK Ltd, Host Access Business Unit, The Stables, Cosgrove, Milton Keynes, MK19 7JJ Tel: +44 (0) 1908 267111 Fax: +44 (0) 1908 267112 TeemTalk © 1988-2004 Neoware UK Ltd, All Rights Reserved. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.
Page 4 The material in this user's guide is for information purposes only and is subject to change without notice. Neoware UK Ltd accepts no responsibility for any errors contained herein. Trademarks TeemTalk is a registered trademark of Neoware UK Ltd. ADDS Viewpoint A2 is a trademark of Applied Digital Data Systems Inc. D100, D200 and D410 are trademarks of Data General.
Page 5: Table Of Contents
Introduction ... 1-1 TeemTalk & The X Window System ... 1-1 User's Guide Overview ... 1-2 Terms & Conventions ... 1-4 Getting Started... 2-1 Selecting The Terminal Emulation ... 2-1 Viewdata Mode ... 2-4 Host Communications ... 2-6 Initiating A Telnet Session ... 2-6 Serial Connection ...
Page 6 Contents Mouse Functions ... 4-1 Introduction ... 4-1 Selecting & Copying Text ... 4-1 Graphic Copy & Paste ... 4-2 Moving The Cursor In Block Mode ... 4-2 Show & Action Hotspots ... 4-2 Send Keyword ... 4-3 Redefining The Mouse Buttons ... 4-3 Hotspots ...
Page 7 IBM 3151 Settings ... 6-52 Wyse Settings ... 6-56 IBM 3270 Settings ... 6-61 IBM 5250 Settings ... 6-63 BQ 3107 Settings ... 6-65 Keyboard Macros ... 6-68 Attribute Settings ... 6-71 Mouse Button Actions ... 6-74 Help Menu ... 6-76 DEC VT Emulations ...
Page 8 Contents IBM 3270 Emulation ... 11-1 Introduction ... 11-1 Running The Emulation ... 11-1 IBM 3287-1 Printer Support ... 11-3 Network Virtual Terminal Mode ... 11-3 SysReq Key Support ... 11-3 The Status Line ... 11-4 Keyboard Mapping ... 11-6 Record &...
Page 9 PT250 Emulation ... 15-1 Introduction ... 15-1 The Status Line ... 15-1 Keyboard Mapping ... 15-3 Displaying Alternate Characters ... 15-5 Siemens 97801 Emulation ... 16-1 Introduction ... 16-1 Keyboard Mapping ... 16-1 Stratus V102 Emulation ... 17-1 Introduction ... 17-1 The Status Line ...
Page 10 Contents Display Format ... 20-12 Window Elements ... 20-16 Colour Selection ... 20-19 Font Selection ... 20-22 Understanding X Resources ... 20-26 Key Reference Numbers ... A-1 Keysyms ... B-1 Virtual Keysyms ... B-1 Keysyms & Functions ... B-2 Virtual Key Names ... C-1 Sending Text To A File ...
Page 11: Introduction
Introduction Introduction This chapter introduces the TeemTalk for Unix terminal emulation software and describes the scope of this User's Guide. TeemTalk & The X Window System TeemTalk for Unix is the essential connectivity tool for enabling non-X based applications to be run in the X environment. TeemTalk provides precise emulation of a wide range of industry standard terminals with impressive additional features formu- lated to increase productivity and reduce network loading.
Page 12: User's Guide Overview
Introduction User's Guide Overview Chapter 1: Introduction Introduces TeemTalk and describes various conventions used. Chapter 2: Getting Started Describes how to use TeemTalk and configure it for compatibility with your hardware and the application. Chapter 3: Keyboard Configuration Describes how to configure the keyboard, remap key functions and compose special characters.
Page 13: Key Reference Numbers
Chapter 14: MDIS Prism Emulations Describes features of the McDonnell Douglas Prism-8, Prism-9 and Prism-12 terminal emulations. Chapter 15: PT250 Emulation Describes features of the Prime PT250 emulation. Chapter 16: Siemens 97801 Emulation Describes features of the Siemens 97801 emulation. Chapter 17: Stratus V102 Emulation Describes features of the Stratus V102 emulation.
Page 14: Terms & Conventions
Introduction Terms & Conventions This User's Guide uses the following terms and conventions. 1. When referring to mouse buttons, it will be assumed that the Left button is configured as button 1, the Middle button is configured as button 2, and the Right button is configured as button 3.
Page 15: The Status Line
Getting Started Getting Started This chapter describes how to configure TeemTalk for compatibility with your hardware and the application. Selecting The Terminal Emulation When you load TeemTalk for the first time, the DEC VT400 (7-bit) emulation will be running by default. The current emulation can be changed in one of two ways, either from the status line or by using a setup dialog box.
Page 16: Keyboard Mapping
Getting Started Alpha Emulations The ADDS A2 emulation provides compatibility with software designed to drive the ADDS Viewpoint A2 terminal, as emulated by the Wyse WY-50/50+/60 terminals. Refer to the Wyse Emulations chapter for more details. The AIXTerm emulation provides compatibility with software designed to drive an X terminal using X Windows.
Page 17 Getting Started screen and enable the emulation to function correctly. The setting of the Model option in the IBM 3270 Settings dialog box determines the size of the display and whether or not extended attributes are supported (this must only be changed while running the IBM 3270 emulation and the new setting will not take effect until you save it and restart TeemTalk).
Page 18: Viewdata Mode
Getting Started The VT400 Series-7 and VT400 Series-8 emulations enable you to run applications written for the DEC VT400 terminal, the difference is in their treatment of 8-bit control codes. When VT400 Series-7 is selected, all 8-bit codes are converted to their 7-bit equivalents, whereas VT400 Series-8 leaves 8-bit codes unchanged.
Page 19 Getting Started AT&T 4410 Emulation In AT&T 4410 mode the display size is 80 (or 132) columns by 25 lines with a scroll region of 24 lines. A row of function buttons is displayed along the bottom of the window. These correspond to the function keys F1 through F8 on the keyboard. You can action a programmed function either by pressing the function key or click-ing the equivalent button displayed on the screen.
Page 20: Host Communications
Getting Started Host Communications TeemTalk can communicate with the operating system shell (STDIN and STDOUT) or a host through an RS232 port. TeemTalk also includes a telnet driver for remote host connection so that precise control can be exercised over the information that TeemTalk receives and transmits.
Page 21: Serial Connection
To save the settings so that they will be automatically reasserted when TeemTalk is subsequently reset or loaded, display the File menu and select the Save Settings option. Note that you can use resources or command line options to initiate a telnet session, specify the telnet port number, and force TeemTalk to exit when the connection closes.
Page 22 Getting Started effective baud rate that TeemTalk transmits at. This is used to artificially reduce data rates on higher baud rate interfaces. When the options are set correctly, click Ok to make the changes take effect and close the dialog box. To save the settings so that they will be automatically reasserted when TeemTalk is subsequently reset or loaded, display the File menu and select the Save Settings option.
Page 23: Selecting & Using Window Elements
Getting Started Selecting & Using Window Elements The TeemTalk window consists of various elements which are described in the following sections. The Title Bar The title bar displays the name of your version of TeemTalk software by default. You may change the title displayed by using the title resource or -title command line option followed by a space then the title to be assigned.
Page 24: Window Resize Commands
Getting Started To select an option in the menu, just click the pointer over it. To close the menu without selecting an option, move the pointer outside the menu and click the left mouse button. All the options listed in the menus are described in the Setup Menus chapter.
Page 25: The Scroll Bar
Getting Started The Scroll Bar Displayable data is stored in a buffer which may be larger than the window. The scroll bar down the right edge of the window represents the entire buffer and enables you to display data that is above or below the current view of the window. The number of text lines displayed in the window is specified by the defaultLines resource or -dl command line option (default 24 lines), and the number of lines stored off-screen in the buffer is specified by the saveLines resource or the -sl command line...
Page 26 Getting Started Button 1: This button displays the active session (always 1), the current page number (always 1), and the line,column location of the text cursor. Clicking the button will activate the Hold Screen function, stopping data from scrolling in the window. To resume scrolling, click the button again. Button 2: This button toggles the visibility of the soft buttons displayed at the bottom of the window on and off.
Page 27: The Soft Buttons
Getting Started The Soft Buttons A series of buttons is displayed below the status line at the bottom of the window by default when TeemTalk is loaded. These can be programmed so that they perform various functions when clicked. There are four levels of soft buttons. Each level consists of two rows with six program- mable buttons on each row.
Page 28 Getting Started Notes 2-14...
Page 29: Keyboard Configuration
Keyboard Configuration This chapter describes how to configure TeemTalk for your particular keyboard, remap key functions and compose special characters. Introduction TeemTalk maps the keyboard to be as near as possible to the terminal being emulated. Illustrations showing the mapping of functions are shown in each terminal emulation chapter.
Page 30: Changing The Function Of A Key
Keyboard Configuration Keycode = 13, State = 0, Keysym = 65471 The Keysym value can be directly used in Translation tables as shown in the following example: *xteemx320*vt220.Translations: #override \n\ Changing The Function Of A Key Once the keysym of a particular key is known, you can change the function of that key by using the Translations resource.
Page 31 xteemx320*vt220.Translations: #override \n\ <Key>Meta_R: value(-166) This will cause the line <Key>Meta_R: value(-166) to be added to the beginning of the standard translation table. The effect is to define the keyboard's rightmost Meta key as the Compose Character key. Note: The #override directive following the Translations resource name ensures that if the translation table already assigns a function to a keysym specified by the resource, the new function will replace the old.
Page 32: Programming Keys
Keyboard Configuration Programming Keys The Keyboard Macros dialog box is displayed by selecting Keyboard Macros in the Settings menu. This enables you to program most keys with up to four definitions (macros) each. Keys that cannot be redefined include Shift, Caps Lock and Print Screen.
Page 33: Entering Control Characters
Keyboard Configuration Note: An escape sequence will be sent across a network as a single packet. The Key Expansion Character is a special toggle character that can be inserted into key macro strings to cause subsequent characters to be redirected from the host to the terminal and vice versa.
Page 34: Compose Character Sequences
Keyboard Configuration Compose Character Sequences Compose character sequences can be used to generate codes for characters not shown on your keyboard when you are in VT400 mode. The characters that can be composed depend on the setting of the Multinational Mode and Preferred Fonts options in the Emulation Settings dialog box.
Page 35 Keyboard Configuration The following tables use several conventions: The keys bearing the characters used to compose a special character may be pressed in any order unless (in order) is specified. (DEC Multinat.) indicates that the character can only be composed if the Multinational Mode option in the Emulation Settings dialog box is selected and the DEC MCS option is unselected.
Page 36 Keyboard Configuration COMPOSE CHARACTER SEQUENCES " quotation mark number sign apostrophe commercial at opening bracket back slash closing bracket circumflex accent grave accent opening brace vertical line closing brace tilde ¡ inverted ! ¢ cent sign £ pound sign ¥ yen sign §...
Page 37 COMPOSE CHARACTER SEQUENCES (continued) Ä A " A umlaut Å A ring (degree sign) Æ A E diphthong (in order) Ç C cedilla (in order) È E grave É E acute Ê E circumflex Ë E " E umlaut Ì I grave Í...
Page 38 Keyboard Configuration COMPOSE CHARACTER SEQUENCES (continued) ó o acute ô o circumflex õ o tilde ö o umlaut o e diphthong œ (DEC Multinat.) ø o slash ù u grave ú u acute û u circumflex ü u umlaut ÿ y umlaut no break space (Latin-1)
Page 39: Mouse Functions
This chapter describes the special functions assigned to the mouse buttons by TeemTalk and how to redefine the buttons. Introduction TeemTalk assigns a variety of special functions to the mouse buttons. Each button can be used to action up to five functions when pressed in conjunction with modifier keys. The following table lists the functions assigned to each button and key combination by default.
Page 40: Graphic Copy & Paste
Mouse Functions The default method for selecting text is as follows. Place the cursor at the start of the text to be copied, hold down the Left mouse button (with Shift if a rectangular area is to be selected) then drag the cursor across to the end of the required text. Releasing the mouse button will cause the selected text to be saved in the global cut buffer.
Page 41: Send Keyword
Hotspots are supported in ALL terminal emulation modes. TeemTalk provides a set of default hotspot keywords for each mode. These relate to key functions specific to the emulation. For example, in VT320 mode you can click on the word Help displayed on the screen and TeemTalk will execute the function associated with the Help key.
Page 42 Mouse Functions You can also enter a definition of your own in the text box associated with each button and key combination. Definitions are entered in the same way as for keyboard macros and soft buttons, as described in the Setup Menus chapter. The setting of the Highlight When Actioned option determines whether or not a visual indication is given that a function has been actioned when a hotspot is clicked.
Page 43: Hotspots
This chapter describes the hotspot facility which enables functions to be performed by clicking on keywords displayed on the screen. Using Hotspots TeemTalk incorporates a user-definable hotspot facility which enables you to invoke a function by clicking the mouse pointer over a keyword displayed on the screen. For example, an application may display information relating to keys you can press to perform a particular function.
Page 44: Defining Hotspots
Hotspots Defining Hotspots Hotspot keywords and associated functions are specified in a text file which has the same name (and is in the same directory) as the current save settings file but with the extension .hot instead of .nv. For example, the default hotspot definitions supplied with TeemTalk (with graphics emulations) are stored in the file teemx340.hot.
Page 45 Hotspots The function that will be performed when the keyword is selected is specified in the same way as for key macros, soft buttons and script language programming. Entering Control Characters You can enter a control character in a keyword definition either as the control key character equivalent or the decimal value of the ASCII character.
Page 46 Hotspots To define a keyword so that it will perform the same function as pressing a sequence of keys one after the other, enter each virtual key name in the order required, enclosing each name with the < and > characters. Each enclosed virtual key name must immediately follow the previous enclosed virtual key name with no spaces.
Page 47: Setup Menus
Setup Menus Setup Menus This chapter describes the options available in the setup menus and dialog boxes. Selecting & Closing Menus Three menus labelled File, Settings and Help can be displayed from the menu bar by clicking on the relevant buttons. A menu is closed by moving the pointer away from the menu then clicking the left mouse button.
Page 48: Using The Menus
Setup Menus Using The Menus Option Selection There are several ways of selecting or actioning the various options displayed in the menus. The quickest way is to click the option required. Another way is to place the pointer over the button on the first option, hold down the left mouse button then move the pointer up or down the menu until the button rests over the option required then release the left mouse button.
Page 49: Default Settings
When there are more options that can be comfortably displayed in the dialog box, these will be shown in a list box with a scroll bar. The scroll bar functions in the same way as the scroll bar in the main window. To make a selection, display the required option in the list box then click the pointer on it so that it is highlighted.
Page 50: Menu Descriptions
Setup Menus Menu Descriptions The following pages describe the options available in all the menus and associated dialog boxes. The descriptions begin by showing the menu or dialog box as it is displayed on the screen. The factory default setting is shown below each option title where applicable.
Page 51: Setup Menus
Setup Menus Reset Terminal This will reset the current terminal emulation mode. Save Settings This will save the current setup configuration so that it is reasserted when TeemTalk is subsequently reset or loaded, overriding any changes which have been made but not saved.
Page 52 Setup Menus A telnet session can be initiated from a dialog box while TeemTalk is running or by using resources or command line options. Note that TeemTalk must be configured so that it is running the required terminal emulation before initiating a telnet session. The Type list box is used to specify the type of host connection that is to be made: TCP/IP, SSH2 (optional) or SSL/TLS (optional).
Page 53 Setup Menus The file for storing captured data may be selected either by clicking the pointer over the filename in the Files list box then clicking the Ok button, or by clicking the pointer in the Selection text box, typing the directory path and name of the file, then clicking The Filter text box enables you to select the directory for display in the Directories list box.
Page 54 Setup Menus each line as it is received from the host. Selecting Controller will enable the host to to send text directly to the printer, without displaying it on the screen. Print Screen Clicking this option cause a fast print of text displayed in the TeemTalk window using ASCII text codes.
Page 55 Setup Menus programs. It enables you to run the currently displayed program and will automatically detect and highlight lines that contain errors. Refer to the Script Recorder chapter in the Programmer's Guide for details. Clear Buffer This will cause the contents of the window and scroll buffer to be erased. Quit This will cause TeemTalk to shut down.
Page 56: Telnet Options
Setup Menus Telnet Options This dialog box is displayed when you click the Telnet Options button in the New Connection dialog box. Note that the options available and the default settings depend on the current terminal emulation. The '3270' and '5250' options are only applicable when running the IBM 3270 or IBM 5250 emulations, respectively.
Page 57 Suppress TN3270E When running the IBM 3270 emulation, the setting of this option determines whether or not support of TN3270E is suppressed. When this option is not selected (i.e. TN3270E is not suppressed), additional options are available by clicking the 3270 Options button.
Page 58: 3270 Options
Setup Menus 3270 Options This dialog box is displayed by clicking the 3270 Options button in the Telnet Options dialog box when TN3270 is not suppressed. Connect This specifies the name of the device which the server will be requested to assign to the Telnet session;...
Page 59 Setup Menus When you achieve a TN3270E connection, the LU device name that you are con- nected as will be displayed on the status line. If the specified device is rejected by the server or host, then an error message box will be displayed indicating the reason. Associate This is available when the Model option in the IBM 3270 Settings dialog box is set to 3287-1 (a printer).
Page 60: 5250 Options
Setup Menus 5250 Options This dialog box is displayed by clicking the 5250 Options button in the Telnet Options dialog box when TN5250 is not suppressed and the Model option in the IBM 5250 Settings dialog box is not set to 3812-1 (a printer). Refer to the next section for 5250 Printer Options.
Page 61 Setup Menus Where a device name collision occurs (i.e. the device name is already in use on the host) the host will ask again for the device name during the same connection. In this case TEST1, TEST2, ... may all be tried in one connection until the host accepts one, or all possibilities have been tried.
Page 62: 5250 Printer Options
Setup Menus 5250 Printer Options This dialog box is displayed by clicking the 5250 Options button in the Telnet Options dialog box when TN5250 is not suppressed and the Model option in the IBM 5250 Settings dialog box is set to 3812-1 (a printer). Device Name Specifies the name of the printer device.
Page 63 Mfg. Type and Model Specifies the manufacturer, type and model of the printer. The entry must exactly match an AS400 printer type string, including the * (asterisk) character. The following valid entries are for the IBM AS/400 V3R1. Note that the list can change according to AS/400 settings.
Page 64 Setup Menus Formfeed This is always set to Don't Report. The Paper Source 1 option is used to specify the paper format to be used. Paper Source 1 & 2 These options specify the paper format to be used. The possible settings are: Don't Report *NONE *MFR...
Page 65 Setup Menus ASCII 899 Support Specifies whether the single-byte printer has ASCII code page 899 installed. Selecting Don't Report will cause no value to be returned. WSCST Name Specifies the name of the object containing pointers to the work station customizing tables.
Page 66: Ssl Connection Settings
Setup Menus SSL Connection Settings The optional SSL (Secure Sockets Layer) protocol enables authenticated and encrypted communication between clients and servers. Before anyone can connect to a server the system administrator must make available a copy of the root certificate used to sign the server’s identity certificate and the number of the telnet port the server is listening on.
Page 67: Error Messages
7. In the New Connection dialog box, select the host to connect to in the Connect To list box. 8. Click the Connect button. TeemTalk will attempt to connect to the host. If this is unsuccessful it will display an error message (see below). All the information entered in the SSL Connection dialog box is stored in the .nv file on a per session basis.
Page 68: Ssh Connection Settings
Setup Menus SSH Connection Settings The optional SSH (Secure Shell) client/server protocol is used to encrypt and transmit data securely over a network, with authentication (proof of client identity) provided by a password and/or key. TeemTalk sets the telnet host port number to 22 by default. To make an SSH connection: 1.
Page 69 Setup Menus Key File Authentication Key authentication uses a randomly generated pair of keys, one private, one public, consisting of unique strings of binary data. A copy of the public key is placed in all the accounts to be accessed on the SSH server machines. Your private key, which is protected using a Passphrase, is stored on your local SSH client machine.
Page 70: Password Authentication
Setup Menus Enter a passphrase and then a pair of keys will be generated. The private key is encrypted and stored in a file with the extension .key. The public key is stored in two files, one in OpenSSH format and one in Draft SSH2 format. Password Authentication Password authentication enables you to use your login password as proof of identity.
Page 71: Settings Menu
Emulation Settings Serial Settings Terminal Settings Tek Graphics Settings VT/ANSI/SCO Settings HP 70092 Settings PT 250 Settings TA 6530 Settings IBM 3151 Settings - for specifying the terminal emulation, keyboard nationality and displayable characters. - for specifying host communication settings.
Page 72 Setup Menus Wyse Settings IBM 3270 Settings IBM 5250 Settings BQ 3107/7107 Settings Keyboard Macros Attribute Settings Mouse Button Actions 6-26 - for configuring the Wyse emulations. - for configuring the IBM 3270 emulation. - for configuring the IBM 5250 emulation. - for configuring the BQ 3107 emulation.
Page 73: Emulation Settings
Setup Menus Emulation Settings This dialog box is displayed by selecting Emulation in the Settings menu. Alpha Emulation Factory default: VT320-7 The setting of this option determines the current alpha emulation mode. The ADDS A2 emulation provides compatibility with software designed to drive the ADDS Viewpoint A2 terminal, as emulated by the Wyse WY-50/50+/60 terminals.
Page 74 Setup Menus DOC18 emulates VT220+ (DOC-18). It runs the VT300 8-bit emulation, sets the numeric keypad to application mode, sets the display to 25 lines and enables a special character set. The function of the keys F1 to F4 on the numeric keypad are mapped to the first four function keys in the set of F1 to F12 function keys, and F5 to F12 perform the same functions as the equivalent keys on the VT220 keyboard.
Page 75 Setup Menus The STRATUS V102 emulation provides compatibility with software designed to drive the Stratus V102 terminal. The TA6530 emulation provides compatibility with software designed to drive the Tandem 6526 and 6530 terminals. You must make a host connection using the Telnet facility supplied with TeemTalk in order for this mode to function correctly in block mode applications.
Page 76 Setup Menus Terminal ID Factory default: VT340 This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) The M2200 setting enables TeemTalk to be treated as a Microcolour M2200 series termi- nal.
Page 77 Setup Menus Display Control Codes Factory default: Unselected When selected, a representation of received control codes will be displayed on the screen instead of actioned. Multinational Mode Factory default: Selected The setting of this option determines the type of character set that is used. When Mul- tinational Mode is selected, a character set consisting of two tables of characters is used.
Page 78: Serial Settings
Setup Menus Serial Settings This dialog box is displayed by selecting Serial in the Settings menu. Baud Rate Factory default: 9600 This option specifies the transmit and receive baud rates for the port selected for host communications. Stop Bits Factory default: 1 This option specifies the number of stop bits sent for each transmitted character.
Page 79: Serial Port
Serial Port Factory default: Unspecified This option specifies the name of the serial port device which will be used for host communications when the Use Serial Port option is selected. Click the pointer on the line then enter the name of the device, for example: If an invalid device is specified, or the device cannot be accessed, communication will be defaulted back to the operating system shell.
Page 80: Terminal Settings
Setup Menus Terminal Settings This dialog box is displayed by selecting Terminal in the Settings menu. Cursor Type Factory default: Flashing Block This enables you to specify how the text cursor is displayed. Select from the following: Flashing Underline Flashing Block Columns Factory default: 80 This option enables you to specify a display width of 80 or 132 columns.
Page 81 When the option is selected, resizing the window will cause the number of visible lines to be increased or decreased to fill the new window size without adjusting the character size. When this option is unselected, resizing the window will cause TeemTalk to search a list of known fonts and select the one which allows the same number of rows and columns as before to fill the new window size.
Page 82 Setup Menus Local Echo Factory default: Unselected The setting of this option determines whether characters sent to the host are displayed at the same time, or only displayed if the host echoes them back. When local echo is enabled, TeemTalk will display each character as it is sent to the host. Jump Scroll Factory default: Unselected The setting of this option determines whether data is scrolled one or several lines at a...
Page 83: Tek Graphics Settings
Tek Graphics Settings This dialog box is displayed when running the 4010/4014 emulation by selecting Tek Graphics in the Settings menu. Gin Terminator Factory default: CR/EOT This option determines the termination character(s) that follow a GIN address trans- mission, and can be set to one of the following: CR/EOT GIN terminator (default) None Destructive Backspace...
Page 84: Vt/Ansi/Sco Settings
Setup Menus VT/ANSI/SCO Settings This dialog box is displayed by selecting VT/ANSI/SCO in the Settings menu. The options available depend on the emulation you are running. Status Line Factory default: Indicator The last line in the window can be used to display a status line when running any of the DEC VT terminal emulations.
Page 85 Vertical VT420 Coupling Factory default: Selected The setting of this VT420 emulation option determines what happens when the application moves the cursor to a line not currently displayed in the window when the number of displayed lines is less than the page size. When selected, the display will automatically scroll vertically to keep the cursor in view.
Page 86 Setup Menus When unselected, the keys will generate characters corresponding to the legends on the keycaps (or their stored strings if they have been programmed). When this option is selected, the keys will generate control functions when pressed. Note: On some keyboards these keys act as both a numeric keypad and a cursor key block depending on the setting of a modifier, for example the Num Lock key.
Page 87 Setup Menus Answerback String Factory default: Unspecified This option enables you to specify the Answerback string that is sent to the host in response to an emulation enquiry command. The string may be up to 30 characters long. Concealed Factory default: Unselected Selecting this option will cause the Answerback string to be locked from change and displayed as asterisks.
Page 88: Hp700/92 Settings
Setup Menus HP700/92 Settings This dialog box is displayed by selecting HP 70092 in the Settings menu. Local Echo Factory default: Unselected The setting of this option determines whether or not keyboard entered characters are displayed on the screen as well as sent to the host.
Page 89 Setup Menus EscXfer Factory default: Unselected The setting of this option determines whether escape sequences relating to the display are sent when the display memory is transferred to the printer. When unselected, escape sequences relating to the display are not sent to the printer. When selected, each line transferred to the printer will begin with an escape sequence to select the primary character set and stop any character enhancements.
Page 90 Setup Menus InhEolWrp (C) Factory default: Unselected The Inhibit End of line Wrap option determines whether characters wrap to the next line when the right margin is reached. When selected (i.e. inhibited), on reaching the right margin, the last character position will be overwritten with every new character received until a carriage return or other cursor movement command is issued.
Page 91 Typeahead Enabled Factory default: Unselected When TeemTalk is connected to an HP 3000, you normally have to wait for the host to send a prompt before you can enter new data at the keyboard, otherwise the data is ignored. Selecting this option will enable you to type continuously without waiting for the prompt.
Page 92 This option enables you to specify the prompt character for your particular host. Most hosts either use the DC1 (^Q) character (e.g. HP 3000) or no prompt (^@) character. When Typeahead Enabled is selected, TeemTalk will wait for the specified prompt character from the host before transmitting the next line from the keyboard buffer.
Page 93: Pt250 Settings
Setup Menus PT250 Settings This dialog box is displayed by selecting PT 250 in the Settings menu. Block Mode Factory default: Unselected This option determines how data is transmitted to the host. When this option is unselected each character entered from the keyboard is immedi- ately sent to the host which processes it then echoes it back to the display.
Page 94 Setup Menus When unselected, the character set for the keyboard nationality specified in the Mode Settings dialog box is mapped to G0, the default character set mode (as indicated on the status line). In effect, national characters from the Additional character set are swapped with Standard (ASCII) characters to form the National set mapped to G0, so the Additional set contains the missing ASCII characters.
Page 95 Setup Menus Received LF is CR/LF Factory default: Unselected The setting of this option determines how the emulation interprets received line feed characters. Selecting it will cause a carriage return command to be appended to every line feed command received. Received CR is CR/LF Factory default: Unselected The setting of this option determines how the emulation interprets received carriage...
Page 96: Ta6530 Settings
Setup Menus TA6530 Settings This dialog box is displayed by selecting TA 6530 in the Settings menu. Power On Mode Factory default: Conversational This option determines the operating mode that is in effect when the TA6530 emulation is entered after loading TeemTalk. Note: Changing the current setting will not take effect until you re- load TeemTalk, so you will need to save the new setting before exiting TeemTalk.
Page 97 Setup Menus Status Border Factory default: Unselected This option enables you to display a thin border which separates the status line from the rest of the lines on the display. Return Function Factory default: Unselected This option specifies whether or not the function of the Enter key is defined by the application when in Block mode.
Page 98: Ibm 3151 Settings
Setup Menus IBM 3151 Settings This dialog box is displayed by selecting IBM 3151 in the Settings menu. Operating Mode Factory default: Echo The setting of this option determines how keyboard entered data is sent to the host and displayed on the screen. In Echo mode, keyboard entered data is sent only to the host.
Page 99 Setup Menus Turnaround Char Factory default: CR This option specifies the line turnaround character (LTC) that is generated when a Read command is received or one of the block data transmission keys is pressed. Note that selecting DC3 will disable the XON/XOFF inbound and outbound pacing charac- ters.
Page 100 Setup Menus Enter Key Factory default: Return This option enables you to specify whether the Enter key performs the same function as the Return key or the Send key. Return Key Factory default: Field This option specifies whether or not the cursor can enter a line within a protected field when the Return key is pressed.
Page 101 Setup Menus When selected, the cursor will automatically move to the beginning of the next line. Note that this will always be the case in block mode or in a formatted page regardless of the setting of this option. When unselected, the cursor will remain at the end of the current line and each new character sent to the display will overwrite the character already occupying the cursor position.
Page 102: Wyse Settings
Setup Menus Wyse Settings This dialog box is displayed by selecting Wyse in the Settings menu. Note that some of the settings apply to the TVI 910+, TVI 920, TVI 925, ADDS A2 and HZ 1500 emulations in addition to the Wyse emulations. Also, some settings may not apply to the particular Wyse emulation currently running.
Page 103: Status Line
Setup Menus The 1 + Rest setting will divide the display memory into two pages, the first containing the number of lines specified by the Lines option, the second containing all the remaining lines. Note that changing the page format will cause the entire display memory to be cleared, the cursor will move to the home position and the scroll margin will be reset.
Page 104 Setup Menus WPRT Attribute Factory default: Dim This option applies to all emulations and enables you to specify the appearance of write-protected characters on the display. They can be displayed in reverse video, dimmed or blinking. The WY-50+ and WY-60 emulations also support the underline and invisible attributes.
Page 105 Setup Menus When selected, a new page of memory will be displayed. Note: The other emulations do not support multiple pages, so the cursor moves according to the Auto Scroll option. DEL = DestBS Factory default: Unselected This option applies to the WY-50+ and WY-60 emulations and determines what effect an ASCII DEL character has on displayed characters.
Page 106 Setup Menus Colour Support Factory default: Unselected When this option is selected, TeemTalk will recognize an additional set of host com- mands which determine the colours used for the display. Wyse 350 colour commands will be recognized in all modes except Wyse 60, which will use Wyse 60 colour com- mands.
Page 107: Ibm 3270 Settings
IBM 3270 Settings This dialog box is displayed by selecting IBM 3270 in the Settings menu. Model Factory default: 3278-2-E This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) It also determines the size of the display and whether or not extended attributes are supported when the current alpha emulation is set to IBM 3270.
Page 108 Setup Menus Print By Pass This option is available when the Model option is set to a printer. The Start Seq box enables you to enter the character or sequence of characters that initiate a print bypass. The end sequence that terminates the print bypass can be specified either by entering the actual characters in the End Seq box when Specify End Sequence is selected, or by specifying the number of characters that make up the end sequence in the End Length box when End On Non-Hex is selected.
Page 109: Ibm 5250 Settings
IBM 5250 Settings This dialog box is displayed by selecting IBM 5250 in the Settings menu. Model Factory default: 3179_2 This specifies what is reported back to the host in response to a terminal identification request. (Note that not all features of the specified terminal may be supported.) The terminal types supported and their display characteristics are listed below.
Page 110 Setup Menus Ruler Line Style Factory default: Cross A rule can be displayed across the emulation workspace at the cursor position by holding down the modifier key Alt, Meta or Extend Char and pressing Page Down, which toggles it on and off. The setting of this option determines whether it is displayed as a horizontal rule, vertical rule or both (cross).
Page 111: Bq 3107 Settings
Setup Menus BQ 3107 Settings This dialog box is displayed by selecting BQ 3107 in the Settings menu. Rendition Mode Factory default: VIP The setting of this option determines whether VIP or SDP display attributes are used. VIP Mode Factory default: 7760 The VIP mode can be set to 7700 or 7760.
Page 112 Setup Menus Message Row Factory default: At Row 25 The setting of this option determines whether the message row (Partition 0) is at the top or bottom of the display. Fill Character Factory default: Asterix When inserting or deleting characters, the setting of this option determines whether a Space or Asterisk character is displayed.
Page 113 Setup Menus Auto Wrap Tabbing Factory default: Unselected When the last unprotected field on the screen is filled, the setting of this option deter- mines whether or not the cursor automatically moves back to the first field on the screen. Function Keys The keys mapped as FKC1 to FKC12 on your keyboard can be programmed to send control sequences or messages when pressed.
Page 114: Keyboard Macros
Setup Menus Keyboard Macros This dialog box is displayed by selecting Keyboard Macros in the Settings menu. Key Expansion Enabled Factory default: Selected This option specifies whether programmed keys on the keyboard can be expanded (i.e. transmit their programmed contents to the host) when pressed. When selected, a pro- grammed key will send its programmed string instead of its normal character.
Page 115 The key execute character is specified as the control key character equivalent. For example, the default value ^P represents the keys Ctrl + P, which would generate the ASCII control character DLE when pressed. Program Key With These options enable you to program most keys with up to four definitions (macros) each, and the soft buttons with one definition each.
Page 116: Running A Script File
Setup Menus enable the definition to be saved when you select the Save Settings option in the File menu. The large text box will display the reference numbers of all the currently programmed keys and their definitions, and soft button labels and definitions. All volatile and non-volatile key and soft button definitions can be deleted by clicking the Delete All Macros button.
Page 117: Attribute Settings
Setup Menus Attribute Settings This dialog box is displayed by selecting Attributes in the Settings menu. This enables you to specify the colours used in the window and how text with attributes and graphics line styles (except ReGIS) are displayed. To change the way a screen element is displayed, select the relevant item from the Screen Element list box, for example, Bold for characters with the bold attribute.
Page 118 Setup Menus Colour and specify the foreground and background colours on the palettes. To display text assigned with an attribute with both attribute and a particular colour, select Colour, specify the foreground and background colours on the palettes and specify the applicable attribute(s) from the With Attribute list.
Page 119 Setup Menus Colours Cleared With Attribute Factory default: Selected The setting of this option determines whether or not the foreground and background colours are cleared to the default colours when an ANSI clear attributes command is received. Attributes Use Normal Background Factory default: Unselected This option only applies to the IBM 3270 and TA6530 emulations.
Page 120: Mouse Button Actions
Setup Menus Mouse Button Actions This dialog box is displayed by selecting Mouse Button Actions in the Settings menu. This enables you to specify the function of mouse buttons 1, 2 and 3 when they are pressed on their own or in conjunction with modifier keys. You can assign up to five functions for each button.
Page 121 Setup Menus The Show Hotspots and Action Hotspots functions are described in the Hotspots chapter. The Send Keyword function is very similar to the hotspot feature. It enables you to send delimited text displayed on the screen to the host just by clicking on it. Delimiters are the same as for hotspots.
Page 122: Help Menu
Setup Menus Help Menu Clicking the About TeemTalk button in the Help menu will display information on this version of TeemTalk. 6-76...
Page 123: Dec Vt Emulations
DEC VT Emulations This chapter describes features of the DEC VT terminal emulations. Introduction To run a DEC VT terminal emulation, display the Emulation Settings dialog box from the Settings menu and set the Alpha Emulation to one of the emulation options described below, then click OK.
Page 126: The Status Bar
DEC VT Emulations The Status Bar A status line can be displayed on the last line in the window when running any of the DEC VT terminal emulations. An indicator status line is displayed by default on the 25th line the first time you load TeemTalk. You may choose not to display a status line, or enable a host-writable status line to be displayed instead.
Page 127 DEC VT Emulations Not Ready signifies that the printer is not ready to receive data for printing. Ready signifies that the printer is ready to receive data for printing. Auto signifies that the emulation is in Auto Print mode in which the current cursor line is sent to the printer when a command for the cursor to move to the next line is issued.
Page 128 DEC VT Emulations Notes...
Page 129: Bq 3107 Emulation
BQ 3107 Emulation This chapter describes the Bull BQ 3107 terminal emulation. Introduction To run the Bull BQ 3107 terminal emulation, display the Emulation Settings dialog box from the Settings menu and set the Alpha Emulation to BQ 3107, then click The Status Bar The status bar displayed along the bottom of the window will show the status of various operations.
Page 130: Keyboard Mapping
BQ 3107 Emulation Field 7: This is used to display warning messages. Field 8: Not used. Field 9: Not used. Field 10: This will display P.DISCT when the printer is disconnected. Field 11: This will display OVERFLOW when there is a data overflow. Field 12: Indicates the current line and column position of the cursor relative to the top left corner of the display, which is L01:C01.
Page 132 BQ 3107 Emulation Notes...
Page 133: Dg410 Emulation
This chapter describes features of the Data General D410 terminal emulation. Introduction The emulation of the Data General D410 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to DG410. Click Ok to close the dialog box. Keyboard Mapping The illustration on the following page shows where DG410 keyboard functions are mapped to keys on the Enhanced AT keyboard layout.
Page 134 All unmarked keys function as indicated by the legends on the keycaps. Meta key usage: Functions in brackets are generated when the keys are shifted. Normal key usage: (Meta is LOCAL F11 F12 PRINT ER PG DELETE on the Sun 5 keyboard and Alt on the Enhanced AT keyboard) CURS = Cursor Type (CURS)
Page 135: Cursor Type
Cursor Type This key enables you to change the appearance of the cursor. By default the cursor is displayed as a reverse video block. Pressing and releasing the Cursor Type key one or more times will cause the cursor display to change in the following order: Blinking underline Invisible cursor Blinking reverse video block...
Page 136: Key Codes
DG410 Emulation Key Codes The following table lists the decimal value of codes generated when keys that emulate those found on the Data General keyboard are pressed alone or in conjunction with the Shift and/or Ctrl keys. Note that each code shown is the second code generated when the key or key combina- tion is pressed, the first always being the code RS (Hex 1E).
Page 137: Hp700/92 Emulation
HP700/92 Emulation This chapter describes features of the Hewlett Packard 700/92 terminal emulation. Introduction The emulation of the Hewlett Packard 700/92 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to HP70092. Clicking Ok will close the dialog box and TeemTalk will be in HP700/92 mode, as indicated by the following row of buttons displayed along the bottom of the window.
Page 138 INSERT DELETE CLEAR CLEAR SELECT LINE LINE LINE PAGE INSERT Control key usage: All unmarked keys function as indicated by the legends on the keycaps. LINE Normal key usage: Functions in brackets are generated when the keys are shifted. Control: USER KEYS DEFINITIONS SOFT HARD USER...
Page 139: Buttons & Function Keys
HP700/92 Emulation Buttons & Function Keys The buttons along the bottom of the HP700/92 window, except for the middle button, indicate the current function of keys F1 through F8 on the keyboard, each key and equivalent button having several functions within the emulation. The buttons and equivalent function keys enable selection of various operating modes and display configurations.
Page 140 HP700/92 Emulation Modify All - F2 This is similar to the Line Modify F1 function described previously, the only difference being that the editing mode is not exited when Return or Enter is pressed. F2 and its equivalent button acts as a toggle key, switching the mode on or off. The setting may be saved by selecting Save Settings in the File menu.
Page 141 Terminal Test - F5 When this button or F5 key is pressed, the HP700/92 emulation will perform a self-test and display a test screen showing all the displayable characters. Memory Lock - F6 This enables data to be locked on the display so that it is not scrolled off the top of the window when display memory is full.
Page 142: Configuration Selection
HP700/92 Emulation Note: If the XmitFnctn (A) option is selected in the HP70092 Settings dialog box, the button and F7 key will not deactivate Display Functions mode. Auto LF - F8 This button and the F8 key enables or disables Auto Line Feed mode. When enabled, a line feed command is automatically appended to every carriage return command generated from the keyboard.
Page 143 Device Modes - F1 Clicking this button or pressing F1 will cause the Device Modes function labels to be displayed. The keys F1 through F8 will function as described in the following section entitled Device Modes. To Ext Dev - F2 This toggle function determines whether data is sent to the printer or not.
Page 144: Device Modes
HP700/92 Emulation Copy Line - F8 When a printer is connected and enabled by the To Ext Dev function, clicking this button or pressing F8 will cause a copy of the line containing the cursor to be sent to the printer. The cursor will move to the leftmost column on the next line when the line has been printed.
Page 145: Margins, Tabs & Start Column
Log Bottom remains activated until either this button or F3 is pressed again, Log Top is activated, a reset is performed, or the emulation is exited. Log Top - F4 When the display memory becomes full and more data is received from the host or keyboard, lines of data from the top of the display are deleted to make way for the new data.
Page 146 HP700/92 Emulation Set Tab - F2 This function enables tab stops to be defined. To define a tab stop, move the cursor to the column to contain the tab and click this button or press F2. Note: Tab stops that do not lie within the left and right margins will be ignored when the Tab key is pressed.
Page 147: Key Programming
To specify the right margin, place the cursor in the column for the margin location and click this button or press F6. The right margin can be reset to column 80 by pressing F7 (this will also reset the left margin to column 1). Note: Margins are disregarded when data is transferred from display memory to the host.
Page 148: Key String Treatment
HP700/92 Emulation Key String Treatment Each f-key and button definition displayed in the menu consists of two lines. The first line begins with the f-key number followed by space then a one-character attribute field. This field will contain either an uppercase L, T or N. These characters indicate the following: The key string is executed locally.
Page 149: Character Display Attributes
HP700/92 Emulation Key String Definition The second line of each f-key definition contains the character string that is to be displayed, executed, and/or transmitted to the host when the key or button is pressed. The string may contain alphanumeric characters, control characters, and explicit escape sequence characters entered when Display Functions mode is enabled by pressing F7 or the Display Functns button.
Page 150 HP700/92 Emulation label for the key, for example, Under in the first field and Line in the second for Under Line. Press Tab to move down to the next line. Press F7 to enable Display Functions mode then press Ctrl + [ together or the Esc key, followed by the charac- ters &d and the attribute character, which for underline is D.
Page 151: Ibm 3270 Emulation
IBM 3270 Emulation This chapter describes features of the IBM 3270 terminal emulation. Introduction The IBM 3270 emulator provides emulation of all four models of the IBM 3278 alphanumeric terminal and also supports the IBM 3287-1 printer. The terminal emulation supports Extended Attribute mode which allows different representation of highlighted fields and permits host definition of text colours.
Page 152 IBM 3270 Emulation Settings with the -E extension provide support for the following extended attributes: 3270 field attributes, extended highlighting (blink, flash and under- score, but not in combination), foreground colour, and query reply inbound structured fields. These attributes are also supported by the 3279. Click Ok to close the dialog box.
Page 153: Ibm 3287-1 Printer Support
IBM 3287-1 Printer Support TN3287 printing is supported by setting the Model option in the IBM 3270 Settings dialog box to 3287-1. When a new Telnet connection is made, the TeemTalk window display will change to show a message box which will indicate the current printer status.
Page 154: The Status Line
IBM 3270 Emulation The Status Line The last line in the window is used to display status information in the form of symbols and alphanumeric characters. A coloured line separates status information from the rest of the display. Information is displayed in any of five regions within the status line as listed below.
Page 155: Do Not Enter
Readiness & System Connection This indicates that a Telnet session is running. This indicates that the protocol for communication between an application program and the IBM 3270 emulation is not system network architecture (SNA). This indicates that the current screen is a Network Virtual Terminal screen.
Page 156: Keyboard Mapping
IBM 3270 Emulation Perform a cursor-select operation when the cursor is not in a valid cursor-select field. The keyboard can be unlocked and the indicator removed by pressing the Reset key. SYSTEM Indicates that you cannot enter any data because the applica- tion program has disabled the keyboard following an entry.
Page 157 NO FUNCT FUNCT FUNCT FUNCT FUNCT...
Page 158: Record & Playback Keystrokes Facility
IBM 3270 Emulation Record & Playback Keystrokes Facility The record/playback keystrokes facility enables you to eliminate repetitive operations by using the Fn keys to store, retrieve and display data. The Fn keys can store a total of 1500 keystrokes. A sequence of recorded keystrokes may be interrupted so that keystrokes can be entered manually before continuing with the recording or playback.
Page 159: Playback Keystrokes
Note: You can cancel the newly recorded keystrokes by pressing the Quit key. This cancellation does not affect the previously recorded keystrokes. 4. To finish and save the recording, press the Record key. Playback Keystrokes 1. Position the text cursor where the playback is to start. 2.
Page 160 IBM 3270 Emulation 9007 You pressed an invalid sequence key (e.g. Play) while performing the Record function. Remedy: Press the Reset key. 9010 While performing the Play function, you pressed an Fn key that does not have a keystroke assigned to it. Remedy: Press the Reset key.
Page 161: Ibm 5250 Emulation
IBM 5250 Emulation This chapter describes features of the IBM 5250 terminal emulation. Introduction The IBM 5250 emulator provides emulation of 5250 type alphanumeric terminals, both monochrome (green/white plus attributes) and colour. Colours may be modified using the Attribute Settings dialog box. This emulation can be used for connection to an IBM AS/400, System/36 or System/38.
Page 162: Network Virtual Terminal Mode
IBM 5250 Emulation 3180_2 3477_FC 3477_FG 3486_BA 3487_HA 3487_HC The printer types supported are listed below: 3812-1 3. Select Open Telnet in the File menu. Specify the name of the host to which connection is to be made then click Ok. (Refer to the Setup Menus chapter for a description of the Open Telnet dialog box).
Page 163: The Status Line
The Status Line The last line in the window is used to display status information in the form of symbols and alphanumeric characters. A coloured line separates status information from the rest of the display. Information is displayed in any of six regions within the status line as listed below.
Page 165: Record & Playback Keystrokes Facility
Record & Playback Keystrokes Facility The record/playback keystrokes facility enables you to eliminate repetitive operations by using the Fn keys to store, retrieve and display data. The Fn keys can store a total of 1500 keystrokes. A sequence of recorded keystrokes may be interrupted so that keystrokes can be entered manually before continuing with the recording or playback.
Page 166: Playback Keystrokes
IBM 5250 Emulation Note: You can cancel the newly recorded keystrokes by pressing the Quit key. This cancellation does not affect the previously recorded keystrokes. 4. To finish and save the recording, press the Record key. Playback Keystrokes 1. Position the text cursor where the playback is to start. 2.
Page 167: Fax Image Support
9003 You pressed an invalid Fn key while performing the Record or Play function. Remedy: Press the Reset key. 9007 You pressed an invalid sequence key (e.g. Play) while performing the Record function. Remedy: Press the Reset key. 9010 While performing the Play function, you pressed an Fn key that does not have a keystroke assigned to it.
Page 168 IBM 5250 Emulation Notes 12-8...
Page 169: Ibm 3151 Emulation
IBM 3151 Emulation This chapter describes features of the IBM 3151 terminal emulation. Introduction The optional IBM 3151 emulation is based on the native mode of the IBM 3151 Model 11 terminal. You can run the emulation by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to IBM 3151.
Page 170 IBM 3151 Emulation ECHO Field 1: Indicates the current operating mode. mode, keyboard entered data is displayed and processed lo- In BLOCK cally, allowing you to edit it before a block of data is sent to the host. mode, keyboard entered data is sent simultaneously to the host In CHAR and the display.
Page 171: Defining Function Keys
If two or more messages are sent to a particular field, then the message with the highest priority will be displayed. Messages in field 3 are displayed in the following order: Defining Function Keys The keys mapped as F1 through F12 can be redefined from the keyboard or by the host.
Page 172: Keyboard Mapping
IBM 3151 Emulation You can erase the character at the current cursor position by pressing the keys Ctrl + 2. If you want to restore the default definition, press the Clear key while the cursor is in field B. 4. Press the Send key to store the key definition. The function key menu will be cleared to allow you to enter the next key definition.
Page 173 DEF F RESET PR MSG BREAK P SCR F1 functions as RESET when used in conjunction with Meta. All unmarked keys function as indicated by the legends on the keycaps. Control key usage: DEF F Functions in brackets are generated when the keys are shifted. Normal key usage: (Meta is S MSG...
Page 174 IBM 3151 Emulation Notes 13-6...
Page 175: Mdis Prism Emulations
MDIS Prism Emulations This chapter describes features of the MDIS P8, P9 and P12 terminal emulations. Introduction The emulation of the McDonnell Douglas P12, P8 or P9 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to MDI P8\P12 or MDI P9, respectively.
Page 177: Pt250 Emulation
This chapter describes the Prime PT250 terminal emulation. Introduction The emulation of the Prime PT250 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to PT250. Click Ok to close the dialog box. The PT250 emulation is configured via the PT250 Settings dialog box which is described in the Setup Menus chapter.
Page 178 PT250 Emulation Field 3: Indicates the mode of data transmission as follows: CHAR indicates that the emulation is in Character mode in which each character is sent to the host when it is typed at the keyboard. CNTRL indicates that the emulation is in Control Representation mode in which all received data and commands from the host or keyboard are displayed but not acted upon.
Page 179: Keyboard Mapping
ALPHA ONLY indicates that you have attempted to enter non-alphabetic data in a field reserved for alphabetic characters when in Block mode. ALPHANUMERIC indicates that you have attempted to enter non- alphanumeric data in a field reserved for alphanumeric characters when in Block mode.
Page 180 TAB functions as BACKTAB when shifted. CHARSET is a toggle function. BACKTAB CHARSET All unmarked keys function as indicated by the legends on the keycaps. Meta key usage: Functions in brackets are generated when Num Lock is OFF. Normal key usage: (Meta is HELP MENU...
Page 181: Displaying Alternate Characters
PT250 Emulation Displaying Alternate Characters PT250 mode uses two character sets called Standard and Alternate to display characters. Both sets incorporate all the characters contained in the ASCII (7-bit or lower half) and PT250 Additional (8-bit or upper half) character set tables shown in the Character Sets appendix in the Programmer's Guide.
Page 182 PT250 Emulation Alternate Equivalents Of Standard Characters ¡ " ¶ £ ¤ ¥ & ´ § ¨ © ª « < ® > 15-6 ° À ± Á Ñ Â Ò Ã Ó Ä Ô µ Å Õ ¢ Æ Ö...
Page 183: Siemens 97801 Emulation
Siemens 97801 Emulation This chapter describes the Siemens 97801 terminal emulation. Introduction The emulation of the Siemens 97801 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Siemens 97801. Click Ok to close the dialog box. Keyboard Mapping The following illustration shows where Siemens 97801 keyboard functions are mapped to keys on the Enhanced AT keyboard layout.
Page 185: Stratus V102 Emulation
Stratus V102 Emulation This chapter describes features of the Stratus V102 terminal emulation. Introduction The emulation of the Stratus V102 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Stratus V102.
Page 187: Ta6530 Emulation
TA6530 Emulation This chapter describes the Tandem 6530 terminal emulation. Introduction The emulation of the Tandem 6530 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to TA6530. Click Ok to close the dialog box. You must use the inbuilt telnet facility provided by TeemTalk to make a connection to a remote host when using this mode.
Page 188: Operating Modes
TA6530 Emulation ANSI The emulation is operating in ANSI mode. BLOCK The emulation is operating in Block mode. CNTRL Display controls mode activated. In this mode, received control codes will be displayed but not actioned. CONV The emulation is operating in Conversational mode. HOLD Hold screen is activated.
Page 189: Keyboard Mapping
TA6530 Emulation Display memory is treated as one long page consisting of 400 lines, of which 24 lines may be viewed at any one time. Lines above or below those currently displayed may be scrolled into view using cursor or display control keys. Once all the display memory has been used, new data will force all previous lines of data up one line so that the first line is erased, ensuring that the oldest data is erased first.
Page 190 (DEL) (BACKTAB) Numeric keypad bracketed functions are generated when Num Lock is OFF. Meta key usage: RESET Bracketed functions not on the Numeric keypad are generated when shifted. Normal key usage: BREAK (Meta is PRINT F10 F11 F12 SCRN with Control INSERT CHAR DELETE...
Page 191: Wyse Emulations
This chapter describes features of the Wyse WY-50, WY-50+ and WY-60 terminal emulations. Introduction The emulation of the Wyse WY-50, WY-50+ or WY-60 terminal is entered by displaying the Emulation Settings dialog box from the Settings menu and setting the Alpha Emulation option to Wyse 50, Wyse 50+ or Wyse 60.
Page 192: Status Line Messages
Wyse Emulations Status Line Messages The status line at the top of the window is divided into two sections. The left section displays messages relating to the emulation and the right section is used to display messages from the host. The type of status line displayed is determined by the setting of the Status Line option in the Wyse Settings dialog box.
Page 193: Keyboard Mapping
Field 5: >AUX indicates that the emulation is in auxiliary print or transparent print mode. <AUX indicates that the emulation is in auxiliary receive mode. =AUX indicates that the emulation is in auxiliary receive mode and auxiliary print mode. %AUX indicates that a print screen operation is in progress. Standard Status Line Field 6: rrr-ccc indicates the current row and column position of the cursor.
Page 194 F1 - F16 function as F17 - F32 when shifted. (BACKTAB) Numeric keypad bracketed functions are generated when Num Lock is OFF. Meta key usage: Bracketed functions not on the Numeric keypad are generated when shifted. Normal key usage: (Meta is (SEND) F11 F12 PRINT...
Page 195: Resources & Command Line Options
Command Line Options This chapter describes how to use resources and command line options to specify how TeemTalk is run and displayed by the X Window System. Introduction Resources are used to specify how TeemTalk is run and displayed by the X Window System.
Page 196: Resource Format
Resources & Command Line Options Resource Format There are a number of files in which resources are specified. Generally they are specified in the user's .Xdefaults file or the system wide application defaults file. The .Xdefaults file resides in the user's home directory and resources specified in it only affect invocations of TeemTalk made by the owning user.
Page 197: Command Summary
Command Summary General Operation & Setup Command Function X server for display & input Sync signal to X server freq. Resource information file Resource in command line Run script file Setup settings file Emulation to run on startup Debug mode Input queue size Prevent message display Cut &...
Page 198 Resources & Command Line Options Window Elements Command Function Scroll bar enabled/disabled Menu bar enabled/disabled Menus enabled/disabled DEC status line user active Soft button levels displayed Text cursor style Mouse cursor style Colour Selection Command Function Colour map writing Pseudocolour mode Text window foreground Text window background Text cursor colour...
Page 199: General Operation & Setup
General Operation & Setup Server For TeemTalk Display & Input Resource: xteemx340*display: host:server.screen Command Line: -display host:server.screen Default Setting: Determined by the DISPLAY environment variable. These commands specify which X server is to be used to display data and take input when TeemTalk is being run on a remote system.
Page 200: Run Script File
Resources & Command Line Options These will select the following files from the .Xdefaults file: TeemTalk1*title: TeemTalk - Test One TeemTalk2*title: TeemTalk - Test Two Specify Resource On Command Line Resource: None Command Line: -xrm resource string Default Setting: Not applicable This allows a resource specification to be included on the command line as an argument.
Page 201: Emulation To Run On Startup
Emulation To Run On Startup Resource: xteemx340*emuLation: emulation# Command Line: -em emulation# Default Setting: VT400 7-bit These commands enable you to specify the terminal emulation that TeemTalk runs when it is started, where emulation# is a numeric value corresponding to the emulation as indicated below: VT52 VT100...
Page 202: Input Queue Size
Resources & Command Line Options Input Queue Size Resource: xteemx340*inputQueue: 0-4096 Command Line: -q or -Q 0-4096 Default Setting: 255 These commands enable you to set the input queue size for network data. The size of the input queue will determine how quickly an interrupt command takes effect. Prevent Message Display Resource: xteemx340*quiet: on/off...
Page 203: Ibm Reply Mode
Cursor Line Selection Extent Resource: xteemx340*cutToBeginningOfLine: on/off Command Line: -cb cursor to end of line entire cursor line Default Setting: Cursor to end of line. These commands enable you to specify how much of the cursor line is selected when the mouse button is clicked three times in quick succession.
Page 204: Telnet Session
Resources & Command Line Options Telnet Session Telnet Dialog Not Displayed On Startup Resource: xteemx340*tnStartup: off Command Line: +tnstartup -tnstartup Default Setting: Telnet dialog displayed These commands will prevent the Open Telnet dialog box being displayed on startup. Initiate Telnet Session With Host Resource: xteemx340*tnHost: hostname Command Line: -tnhost hostname...
Page 205: Telnet Keepalive Messages
Telnet Keepalive Messages Resource: xteemx340*tnKeepalive: on/off Command Line: -tnkeepalive +tnkeepalive Default Setting: Enabled These commands allow you to enable or disable telnet keepalive messages when using the TeemTalk telnet driver. Closed Telnet Session Exits TeemTalk Resource: xteemx340*tnExit: on Command Line: -tnexit Default Setting: off (message box displayed) When a telnet session is closed, TeemTalk normally displays a message box giving you the option to reconnect, cancel or exit.
Page 206: Display Format
Resources & Command Line Options Display Format Window Maximized When Loaded Resource: xteemx340*maXimized: on Command Line: -ma These commands will cause the window to be displayed at the maximum size possible when TeemTalk is loaded, while retaining the default number of lines and columns and including all window elements if enabled (title bar, soft buttons etc.).
Page 207 This enables the size and location of the TeemTalk window to be specified. The -geometry = option may be abbreviated to -g =. Note: The effect of these commands is determined by the window manager which may have its own rules for window size and position on the display.
Page 208 Resources & Command Line Options Text Lines Displayed When TeemTalk Loaded Resource: xteemx340*defaultLines: number of lines Command Line: -dl number of lines Default Setting: 24 (with status line on 25th line) These commands specify the number of text lines displayed in the window when TeemTalk is loaded.
Page 209: Save 4014 Graphics Display
ReGIS Graphics Redraw Resource: xteemx340*graphicsRedraw: on/off Command Line: -gr enables ReGIS graphics redraw disables ReGIS graphics redraw Default Setting: on TeemTalk automatically redraws the ReGIS graphics screen when the window is resized. You can disable this function using these commands. Sixel Graphics Scaling Resource: xteemx340*scaleSixels: on/off...
Page 210: Window Elements
Resources & Command Line Options Window Elements In addition to the following commands, the section entitled Object Names Available In TeemTalk towards the end of this chapter lists the names given to various elements of the window which can be used to specify whether or not they are enabled and how they are displayed using standard X resource commands.
Page 211 Settings Menu: xteemx340*Settings*Emulation*Sensitive: true/false xteemx340*Settings*Host*Sensitive: true/false xteemx340*Settings*Terminal*Sensitive: true/false xteemx340*Settings*Graphics*Sensitive: true/false xteemx340*Settings*HP*Sensitive: true/false xteemx340*Settings*Blockmode*Sensitive: true/false xteemx320*Settings*PT250*Sensitive: true/false xteemx320*Settings*Tandem6530*Sensitive: true/false xteemx340*Settings*IBM3151*Sensitive: true/false xteemx340*Settings*Wyse*Sensitive: true/false xteemx340*Settings*IBM3270*Sensitive: true/false xteemx340*Settings*IBM5250*Sensitive: true/false xteemx340*Settings*BQ3107*Sensitive: true/false xteemx340*Settings*Macros*Sensitive: true/false...
Page 212: Soft Buttons
Resources & Command Line Options Deactivate DEC Status Line Resource: xteemx340*activeStatusline: on/off Command Line: -as Default Setting: on These commands enable you to specify whether or not the user can change terminal settings using the DEC status line. The status line is active (i.e. the user can change terminal settings) by default.
Page 213: Colour Selection
Colour Selection Colour Mapping Resource: xteemx340*installColormap: on/off Command Line: -ic Default Setting: on Most workstations have only one hardware colour map, a physical register into which colour values are written by the application program for display. As each application will have its own set of colour values (called a virtual colour map), moving the pointer into another window will cause the previous hardware colour map to be overwritten by the virtual colour map of the newly selected window.
Page 214: Foreground (Text) Colour
Resources & Command Line Options Foreground (Text) Colour Resource: xteemx340*foreground: colour (all areas) xteemx340*vt220*foreground: colour (emulation) Command Line: -fg colour Default Setting: black These commands select the colour of the foreground, which includes all menus, window borders as well as the emulation workspace. In the emulation workspace the foreground is considered to be any colour which is white.
Page 215: Reflection 4 Colour Support
Resources & Command Line Options Reflection 4 Colour Support Resource: xteemx340*r4Compatibility: on/off Command Line: -r4 Default Setting: off These commands will cause the colours displayed by TeemTalk to be compatible with Reflection 4 software. 20-21...
Page 216: Font Selection
Resources & Command Line Options Font Selection The fonts that are used for displaying text in the TeemTalk window are specified by the following resources and command line options. Each font selection resource and command line option specifies up to ten fonts. This is to support the window sizing function described in the Getting Started chapter.
Page 217 80 Column Double Width Text Resource: xteemx340*doublewidth80Font: "font list" Command Line: -dwfn80 "font list" Default Fonts: "nil2,tis606,tis708,tis810,trm1212,tis1414,tis1616,tis2020,tis2424,tis2828" This specifies the fonts to use for 80 column double width text. 80 Column Double Height & Width Text Resource: xteemx340*doubled80Font: "font list" Command Line: -dbfn80 "font list"...
Page 218 Resources & Command Line Options 132 Column Double Width Text Resource: xteemx340*doublewidth132Font: "font list" Command Line: -dwfn132 "font list" Default Fonts: "nil2,tis606,tis708,tis810,trm1210,tis1410,trm1610,trm2012,trm2416,trm2820" This specifies the fonts to use for 132 column double width text. 132 Column Double Height & Width Text Resource: xteemx340*doubled132Font: "font list"...
Page 219: Ibm 3270 Font Size Fixed
Resources & Command Line Options IBM 3270 Font Size Fixed Resource: xteemx340*ibmFixedFont: on/off Command Line: -ibmfixed Default Setting: Font size changes to retain same window size When you switch between IBM models while running the IBM 3270 emulation, the size of the font is adjusted by default so that the total number of rows and columns supported by the IBM model selected can be displayed without adjusting the size of the window.
Page 220: Understanding X Resources
Resources & Command Line Options Understanding X Resources Most X clients now implement a simple mechanism of specifying application prefer- ences using preference strings. These preference strings comprise the name of the X client followed by the name of the resource to be set. A colon and then the value to be assigned to the resource follow.
Page 221 Host Settings dialog box. the Terminal Settings dialog box. the VT/ANSI/SCO Settings dialog box. the Graphics Settings dialog box. the HP Settings dialog box. the VT Block Mode Settings dialog box. the Prime PT250 Settings dialog box. the Tandem 6530 Settings dialog box.
Page 222 - e.g. command line options override duplicate entries in the .Xdefaults file. 20-28 File*Capture File*Replay File*CancelCapture File*CancelReplay File*PrinterSettings File*Print File*RunScript File*CancelScript File*ScriptRecorder File*ClearBuffer File*Quit Settings*Emulation Settings*Host Settings*Terminal Settings*Graphics Settings*HP Settings*Blockmode Settings*PT250 Settings*Tandem6530 Settings*IBM3151 Settings*Wyse Settings*IBM3270 Settings*IBM5250 Settings*BQ3107 Settings*Macros Settings*Attributes Settings*Mouse...
Page 223: Command Line
Resources & Command Line Options Command Line Entries on the command line override any other settings specified in other resource files. Whilst most general attributes have equivalent command line arguments, heirarichal ones seldom do have direct equivalents. For example: *foreground: red has the command line equivalent: -fg red *Settings: red does not have a direct equivalent.
Page 224 Resources & Command Line Options Controlling The Resource Database The X utility xrdb is a useful tool for maintaining and debugging the resource database. Whilst full details can be found in all good X guides, a few uses are pre- sented below.
Page 225 Debugging Resources Problems with resource management are seldom attributable to TeemTalk and are more commonly attributable to incorrect syntax or the resource file not being read by the resource manager. Resource files require 100% accuracy in specification; every- thing is case sensitive, the position of white space characters are critical, and non- printable characters inserted in the file causes absolute havoc.
Page 226 Resources & Command Line Options Notes 20-32...
Page 227: Key Reference Numbers
Key Reference Numbers This appendix lists the reference numbers assigned to keys on the British keyboard. National 8-bit Key Reference Numbers NORMAL SHIFT £ ß À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í NORMAL Î...
Page 228 Key Reference Numbers British Keyboard Key Reference Numbers COMPOSE DELETE ENTER ESCAPE FIND HELP INSERT HERE NEXT PREVIOUS REMOVE RETURN SELECT SPACE Keypad 0 Keypad 1 Keypad 2 Keypad 3 Keypad 4 Keypad 5 Keypad 6 Keypad 7 Keypad 8 Keypad 9 Keypad .
Page 229 British Keyboard Key Reference Numbers NORMAL -135 -136 -137 -138 ' " , < . > Key Reference Numbers SHIFT CTRL CT+SH -139 -143 -147 -140 -144 -148 -141 -145 -149 -142 -146 -150...
Page 230: Key Reference Numbers
Key Reference Numbers British Keyboard Key Reference Numbers NORMAL SHIFT CTRL CT+SH...
Page 231: Keysyms
This appendix describes the use of virtual keysyms and lists all the valid keysyms that may be used to define the function of keys Virtual Keysyms The standard X translation tables may be used to redefine the function of most keys on the keyboard.
Page 232: Keysyms & Functions
Keysyms Keysyms & Functions This section lists all the actual keysyms and their functions. The first column in the following tables provides an example of a legend which may be printed on the cap of a key which relates to the function performed or character displayed as described in the second column.
Page 233 Begin Move cursor to beginning of line, BOL Select Select, mark Print Print Execute Execute, run, do Insert Insert, insert here Undo Undo, oops Redo Redo, again Menu Menu Find Find, search Cancel Cancel, abort, exit, stop Help Help, ? Break Break Character set switch, mode switch...
Page 234 Keysyms Keypad 0 Keypad 1 Keypad 2 Keypad 3 Keypad 4 Keypad 5 Keypad 6 Keypad 7 Keypad 8 Keypad 9 Function key 1 Function key 2 Function key 3 Function key 4 Function key 5 Function key 6 Function key 7 Function key 8 Function key 9 Function key 10...
Page 235 Function key 20 Function key 21 Function key 22 Function key 23 Function key 24 Function key 25 Function key 26 Function key 27 Function key 28 Function key 29 Function key 30 Function key 31 Function key 32 Function key 33 Function key 34 Function key 35 Left function key 1 (F11 equivalent)
Page 236 Keysyms Right function key 4 (F24 equivalent) Right function key 5 (F25 equivalent) Right function key 6 (F26 equivalent) Right function key 7 (F27 equivalent) Right function key 8 (F28 equivalent) Right function key 9 (F29 equivalent) Right function key 10 (F30 equivalent) Right function key 11 (F31 equivalent) Right function key 12 (F32 equivalent) Right function key 13 (F33 equivalent)
Page 237 Number sign Dollar sign Percent sign & Ampersand Apostrophe Left parenthesis Right parenthesis Asterisk Plus sign Comma Hyphen, minus sign Full stop Solidus Zero Three Four Five Seven Eight Nine Colon Semicolon < Less than sign Equals sign > Greater than sign Question mark Keysyms FUNCTION...
Page 238 Keysyms Commercial at Uppercase A Uppercase B Uppercase C Uppercase D Uppercase E Uppercase F Uppercase G Uppercase H Uppercase I Uppercase J Uppercase K Uppercase L Uppercase M Uppercase N Uppercase O Uppercase P Uppercase Q Uppercase R Uppercase S Uppercase T Uppercase U Uppercase V...
Page 239 Right square bracket Circumflex accent Low line Grave accent Lowercase a Lowercase b Lowercase c Lowercase d Lowercase e Lowercase f Lowercase g Lowercase h Lowercase i Lowercase j Lowercase k Lowercase l Lowercase m Lowercase n Lowercase o Lowercase p Lowercase q Lowercase r Lowercase s...
Page 240 Keysyms Lowercase z Left brace Vertical line Right brace Tilde No-break space ¡ Inverted exclamation mark ¢ Cent sign £ Pound sign ¤ Currency sign ¥ Yen sign ¦ Broken vertical bar § Paragraph sign, section sign ¨ Diaeresis © Copyright sign ª...
Page 241 ¸ Cedilla ¹ Superscript 1 º Masculine ordinal indicator » Right angle quotation mark ¼ Vulgar fraction one quarter ½ Vulgar fraction one half ¾ Vulgar fraction three quarters ¿ Inverted question mark À Uppercase A with grave accent Á Uppercase A with acute accent Â...
Page 242 Keysyms Õ Uppercase O with tilde Ö Uppercase O with diaeresis × Multiplication sign Ø Uppercase O with oblique stroke Ù Uppercase U with grave accent Ú Uppercase U with acute accent Û Uppercase U with circumflex accent Ü Uppercase U with diaeresis Ý...
Page 243 ò Lowercase o with grave accent ó Lowercase o with acute accent ô Lowercase o with circumflex accent õ Lowercase o with tilde ö Lowercase o with diaeresis ÷ Division sign ø Lowercase o with oblique stroke ù Lowercase u with grave accent ú...
Page 244 Keysyms Notes B-14...
Page 245: Virtual Key Names
Virtual Key Names This appendix lists all the virtual key names supported by TeemTalk. Introduction Virtual key names enable you to include a specific key function in a user definition for key macros, soft buttons, hotspots, etc. The following sections list the virtual key names applicable to each terminal emulation mode.
Page 246: Virtual Key Names
Virtual Key Names AT&T 4410 Virtual Key Names Key Function Virtual Key Name Backspace AT_BACKSPACE Break AT_BREAK Clear AT_CLEAR Cursor Down AT_DOWN Cursor Left AT_LEFT Cursor Right AT_RIGHT Cursor Up AT_UP Delete AT_DELETE Escape AT_ESCAPE BQ 3107 Virtual Key Names Key Function Virtual Key Name Backspace...
Page 247 DEC VT400 Virtual Key Names Key Function Virtual Key Name Back Tab VT_CSIZ Break VT_BREAK Backspace VT_BACKSPACE Compose VT_COMPOSE Cursor Down VT_DOWN Cursor Left VT_LEFT Cursor Right VT_RIGHT Cursor Up VT_UP Datatalk VT_DATATALK Delete VT_DELETE Do (F16) VT_DO Enter VT_ENTER Escape VT_ESCAPE F6 - F14...
Page 248: Ibm 3270 Virtual Key Names
Virtual Key Names HP700/92 Virtual Key Names Key Function Virtual Key Name Backspace HP_BACKSPACE Clear Display HP_CLEARMEM Clear Line HP_CLEARLINE Cursor Down HP_DOWN Cursor Left HP_LEFT Cursor Right HP_RIGHT Cursor Up HP_UP Delete HP_DELETE Delete Character HP_DELETECHAR Delete Line HP_DELETELINE Delete Wrap HP_DELETEWRAP Enter...
Page 249: Ibm 5250 Virtual Key Names
IBM 5250 Virtual Key Names Key Function Virtual Key Name Attention AS_ATTN Back Tab AS_BACKTAB Backspace AS_BACKSPACE Clear AS_CLEAR Cursor Down AS_DOWN Cursor Left AS_LEFT Cursor Right AS_RIGHT Cursor Fast Left AS_FASTLEFT Cursor Fast Right AS_FASTRIGHT Cursor Select AS_CURSORSEL Cursor Up AS_UP Delete Character AS_DELCHAR...
Page 250: Pt250 Virtual Key Names
Virtual Key Names PT250 Virtual Key Names Key Function Virtual Key Name Back Tab PT_BACKTAB Backspace PT_BACKSPACE Break PT_BREAK Cancel PT_CANCEL Change Mode PT_CHNGMODE Character Set PT_CHARSET Clear PT_CLEAR Cursor Down PT_DOWN Cursor Left PT_LEFT Cursor Right PT_RIGHT Cursor Up PT_UP Delete PT_DELETE...
Page 251: Siemens 97801 Virtual Key Names
Siemens 97801 Virtual Key Names Key Function Virtual Key Name Backspace SI_BACKSPACE Back Tab SI_BACKTAB Break SI_BREAK CH Code SI_CHCODE Cursor SI_CURSOR Cursor Down SI_DOWN Cursor Left SI_LEFT Cursor Right SI_RIGHT Cursor Up SI_UP Delete SI_DELETE Delete Character SI_DELCHAR Delete Line SI_DELLINE Delete Word SI_DELWORD...
Page 252: Ta6530 Virtual Key Names
Virtual Key Names TA6530 Virtual Key Names Key Function Virtual Key Name Backspace TA_BACKSPACE Back Tab TA_BACKTAB Break TA_BREAK Character Delete TA_CHARDEL Character Insert TA_CHARINS Cursor Down TA_DOWN Cursor Left TA_LEFT Cursor Right TA_RIGHT Cursor Up TA_UP Delete TA_DEL TA_END Erase Line TA_ERASELINE Erase Page...
Page 253: Viewdata Virtual Key Names
Viewdata Virtual Key Names Key Function Virtual Key Name * (Star) PR_STAR # (Hash) PR_HASH Cancel Print PR_CANCEL Cursor Down PR_DOWN Cursor Left PR_LEFT Wyse Virtual Key Names Key Function Virtual Key Name Backspace WY_BACKSPACE Cursor Down WY_DOWN Cursor Left WY_LEFT Cursor Right WY_RIGHT...
Page 254: Sending Text To A File
Virtual Key Names TeemTalk Virtual Key Name Functions TeemTalk provides additional virtual key name functions for special tasks such as sending text to a file or the serial port, and reading text from a file to place in the keyboard buffer as if typed. Key Function Start Send Text sequence Start Read Text sequence...
Page 255: Reading Text From A File
Virtual Key Names Reading Text From A File The following command format is used to read a string from a file and push it into the keyboard buffer as if typed: <VK_FILE_I><filename>max length,retries,termination char- acter <VK_FEND> The string is terminated when the maximum length is read, or the maximum number of retries is reached, or the termination character is read.
Page 256 Virtual Key Names Notes C-12...
Page 257: Product Specification
Product Specification This appendix describes the level of support provided by each terminal emulation. Introduction The following sections describe the level of support provided by each terminal emulation throughout the product range. Note that your product version may not support all the terminal emulations listed here. General Limitations: Key click not supported.
Page 258 Product Specification Telnet Specification: Implements RFC 854, 855, 856, 857, 858, 860, 1091, 1408, 1571, 1572. Implements RFC 1205, 2877 for IBM 5250. Implements RFC 2355, 1576, 1646, 1647 for IBM 3270. AixTerm Limitations: No Vertical tab stops. No Select Alternate presentation variant. No Select reversed string.
Page 259: Digital Vt Emulation
Digital VT 420 Programmer's Manual (EK-VT420-RM-001). Limitations: The DEC Multisession and SSU protocols are not implemented. HP 700/92 Emulation Specification: HP 2392A Reference Guide (02394-90001. April 1984). IBM 3270 Emulation Specification: 3270 Information Display System Data Stream Programmer's Reference (GA23-0059-07). Limitations: No Right to Left writing mode.
Page 260 Product Specification IBM 5250 Emulation Specification: 5494 Remote Control Unit Functions Reference. Release 2.0. (SC30-3533-02). Limitations: No Right to Left writing mode. No double-byte support. The 3812-1 Non Host Print Transform (Non-HPT) print protocol is not supported. No Calculator / Hex key. No Password encryption.
Page 261: Stratus V102
Stratus V102 Specification: V102 Display Terminal Operator’s Manual (TVI 131974-00 June 1985). Limitations: Page print flip mode not supported. Serial configuration commands not supported. Select character set commands not supported. Tandem 6526/6530 Emulation Specification: Tandem 653x Multi-Page Terminal Programmer’s Guide (82310-B00 December 1983).
Page 262: Televideo 955
Product Specification Televideo 955 Specification: Televideo 955 Display Terminal Operator's Manual (131969-00-B Sept 1985). Limitations: Page print flip mode not supported. Serial configuration commands not supported. Select character set commands not supported. Unisys T27 Specification: Burroughs T27 Programmer’s Reference Manual (1196904 Aug 1986). Limitations: Print protocol, printer sessions and auxiliary i/o are not supported.
Page 263 Function key label save commands not supported. Automatic font loading not supported. Remote caps lock commands not supported. Ignore nulls commands not supported. Attribute overwrite mode not supported. Disable intensity commands not supported. Some select personality commands not supported. Wyseword mode not supported. Wyse 50, 50+, TVI 910, 925, 950, ADDS-A2, HZ 1500, Wyse PC-Term Specification:...
Page 264 Product Specification Notes...
Page 265 Symbols 4010/4014 Emulation Selecting 2-4 ADDS Viewpoint A2 Emulation Selecting 2-2 AIXTerm Emulation 2-2 Specification D-2 ANSI BBS Emulation 2-2 Answerback String VT/ANSI/SCO 6-41 AT 386 Emulation 2-2 AT&T 4410 Emulation Programming function keys 2-5 Selecting 2-2 Virtual key names C-2 Backing Store 20-14 Baud Rate Selection 6-32 Block Mode...
Page 266 Index Deactivate DEC status line 20-18 Debug mode 20-7 Emulation to run on startup 20-7 Font selection 20-22 Foreground (text) colour 20-20 Format 20-2 Host telnet port number 20-10 IBM 3270 font size fixed 20-25 IBM reply mode 20-9 Initiate telnet session 20-10 Input queue size 20-8 Introduction 20-1 Maximize window on loading...
Page 267 Menu enable/disable 20-16 Page arrangement 6-38 ReGIS graphics redraw 20-15 Resize window effect 6-34 Save 4014 graphics 20-15 Scroll bar enable/disable 20-16 Scrolling horizontally 2-11 Sixel graphics scaling 20-15 Soft buttons 2-13 Status line (DEC VT) 6-38 Text attributes 6-71 Window size &...
