6. Replace the access plate:
Figure 2-12
a.
b.
7. Slide the serial number tab into its slots.

Installing the PCI Express Expansion Module and PCI Express Card

Before beginning the replacement process, review
on page 11
WARNING!
power cord is disconnected from the electrical outlet.
Follow the installation instructions included in the PCIe Expansion Module option kit.

External Drives

Various external USB drives are available as options for the st5742/st5747. For more information about
these drives, visit http://h10010.www1.hp.com/wwpc/us/en/sm/WF12a/12454-12454-321959.html, or
refer to the instructions that accompany the option.
For more information about available options, visit the HP Web site at
wwpc/us/en/sm/WF12a/12454-12454-321959.html.
22 Chapter 2 Hardware Changes
Replacing the SO-DIMM access plate
Insert the tab on the front edge into its slot and set the plate into position.
NOTE: You may need to press lightly on the access plate to position it properly against the
chassis.
Replace the two screws to secure the access plate to the chassis.
for procedures you should follow before and after installing or replacing hardware.
Before removing the side access panel, ensure that the thin client is turned off and the
General Hardware Installation Sequence
http://h10010.www1.hp.com/
