Relay Out

Th e relays of the OUT ports can be individually activated using PORT-
OUT ON/OFF statements.
Th e status of the ports can be read by means of PORTIN functions. If a
relay is activated, PORTIN returns the value -1 (true), else it returns the
value 0 (false).
Max AC Load Breaking Capacity
Signal
I
Psw AC
Usw AC
Max DC Load Breaking Capacity
1
0.5
0.1
10
a: resistive load
b: inductive load L/R=20 ms
30
Description
Current
Switching power
Switching voltage
b
a
20 30 40 50
DC Voltage (VDC)
Serial/Industrial Interface Kit Installation Instructions
Max.
1A
100VA AC
100V AC
100
