Industrial Interface
Th is chapter describes the Industrial Interface, which
provides 8 digital IN ports with optocouplers, 8 digi-
tal OUT ports with optocouplers, and 4 OUT ports
with relays.
Th e Industrial Interface has no straps or circuits to be
fi tted or removed. All signals are available on a DB-
44pin socket and the various ports are controlled by
the Intermec Fingerprint instructions PORTIN and
PORTOUT ON/OFF (see Intermec Fingerprint v8.xx,
Programmer's Reference Manual).
Serial/Industrial Interface Kit Installation Instructions
