Chapter 4
REPLACING CONSUMABLES
This chapter describes how to replace scanner consumables.
In this chapter Windows XP screenshots are illustrated.
The screens and operations may differ slightly if the OS that you are using is not Windows XP.
Also, when FUJITSU TWAIN32 is updated the screens and operations noted in this chapter will
differ slightly.
4.1 Consumable and Replacement Cycle ................................................................. 62
4.2 Replacing the Pad ASSY ...................................................................................... 66
4.3 Replacing the Pick Roller..................................................................................... 70
ARNI N G
When operating the scanner, the ADF's inside glass
becomes very hot.
Before you replace the consumables, turn off the power
and unplug the AC adapter from the outlet. Wait for at
least 15 minutes.
