  • Page 1 Fujitsu Scanners Cleaning and Consumable Replacement Instructions fi-4530C & fi-5530C Versitec is a division of Cranel, Inc.
  • Page 2: Table Of Contents

    WARNING !! TURN OFF SCANNER, DISCONNECT FROM POWER ALLOW TO COOL FOR AT LEAST 15 MINUTES BEFORE SERVICING Limitation of Liability Before using this product, please read this manual carefully. If this product is used incorrectly, unforeseen injury may occur. Although best efforts have been made to ensure all information in this manual is correct, Cranel Inc.
  • Page 3 Kit Contents Wipes Cleaning Sheets Foam Swabs V1 Cleaner Pad Assembly Pick Roller...
  • Page 4: Cleaning The Automatic Document Feeder

    Cleaning the Automatic Document Feeder Opening the ADF Location of Parts to be Cleaned...
  • Page 5 Recommended Cleaning Interval During normal use, the ADF is to be thoroughly cleaned every 5,000 scans Scanning certain documents may require more frequent cleaning * Some examples are: Carbonless paper Handwritten documents Paper with special coatings Glossy paper Clean in direction of arrows using either cotton swaps or wipes moistened with V1 cleaner Pick Arm Rollers Pad Assembly...
  • Page 6: Using The Cleaning Paper

    Using the Cleaning Paper Cleaning paper is designed to remove loose dust and ink only. Perform these steps between the manual cleanings described in the previous section With the scanner off, open the ADF Apply V1 Cleaner to both sides of cleaning paper and place in the scanner (the leading edge should touch the top of the...
  • Page 7: Replacing Consumables

    Replacing Consumables Pad Assembly (Recommended every 100,000 sheets) Slide the old pad to the left to remove Install new pad by inserting posts into holes in the adf Slide pad to the right to lock in place...
  • Page 8: Pick Roller

    Pick Roller (Recommended every 200,000 sheets) Remove the sheet guide by depressing the tabs and pulling out Rotate bushing and lift out shaft assembly Place new pick roller onto shaft so Lift tab and remove roller that screw slides into slot When installing sheet guide, Insert end of pick shaft into bushing make sure tabs go into slots...
  • Page 9 Resetting Pick Roller and Pad Assembly Counters After changing consumables, you need to reset the scan counters Click Start. Go to Settings and open the Control Panel Once in the Control Panel window, open Scanners and Cameras Right Click on the scanner and select properties Click the Device Set tab Click the clear buttons...
