3.2

Cleaning the ADF

As a guideline, clean the ADF after every 5,000 scans. Note that this guideline varies according to
the type of documents you are scanning. For example, it may be necessary to clean the ADF more
frequently if documents are scanned when the toner is not sufficiently fixed on the printout.
■ Cleaning Method
1. Open the ADF while pushing down the ADF button.
The glass surface inside the ADF becomes hot during
ARNI N G
the operation of the scanner. Before you start to clean
the inner parts of the scanner, disconnect the AC
adapter from the power outlet, and wait at least 15
minutes.
Do not turn off the scanner when you clean the Feed
and Eject Rollers.
ADF button
Be careful, the ADF cover may close and pinch your
AUTION
fingers.
fi-5530C Image Scanner Operator's Guide
3.2 Cleaning the ADF
55
3
