Installing and Replacing Components Other than Network Interface Cards (NICs) and Accelerated Data Path
To remove a PC card used for logging in an IP690
1. Perform one of the following:
2. Perform a system shutdown by using Network Voyager or the CLI halt command.
3. Press the eject button to remove the PC card.
Caution
To prevent the card from ejecting too quickly, hold the PC card while you push the eject
button.
4. Reboot the system.

Installing a Hard-Disk Drive

The IP690 is a flash-based appliance that also supports one or two optional hard-disk drives that
plug into connectors on the motherboard. Each hard-disk drive contains 40 GB of storage space.
Note
A second hard-disk drive, which can be used for disk mirroring, is an option only for a
disk-based IP690. A single optional hard-disk drive can by used in a flash-based IP690 for
storing log files.
The hard-disk drives are not included in the standard package for the flash-based IP690. When
you purchase your IP690, you can order one or two hard-disk drive(s) for factory installation or
order them later and install them yourself, as described in this chapter.
You can use a single hard-disk drive for storing log files.
This section describes how to install a hard-disk drive.

Before You Begin

Caution
Hard-disk drives are susceptible to damage from shock. Handle them with care.
82
access
In Network Voyager,
Using the CLI, enter the command:
set optional-disk device-id <1 | 2> off
where the number 1 or 2 indicates the PC-card slot.
Optional Disks and unselect the PC card as an optional disk.
