14. From beneath the chassis tray assembly, screw in the bezel retaining screws.
Reinstall the two retaining screws
15. If you removed the FIPS screen, reinstall it in the same position it was previously installed in
and secure the two screen screws.
16. Reinstall the ADP module memory card.
17. Using care to ensure that the top edge of the enclosure does not interfere with the ADP
module heat sink, slide the chassis tray assembly into the chassis until it clicks into place.
18. Tighten the retaining screws that secure the chassis tray assembly.
19. Turn the power on.
20. Use either Network Voyager or the CLI to delete the old interfaces and configure the new
ADP interfaces as described in
on page 67. Note the interface naming conventions in
Names for IP690 Appliances"
64
S L
O T
1
Reinstall the four bezel screws
S L
O T
2
"Configuring Check Point IPSO with IP690 ADP Interfaces"
"Check Point ADP Module Interface
on page 68.
Check Point IP690 Security Platform Installation Guide
ADP module heat sink
