Technical Specifications
Dimensions
Weight
Space Requirements
The Check Point IP690 security platform is designed for front-screw mounting in a standard
19-inch rack. Each IP690 requires the following space in a rack:
3.5 inches (8.9 centimeters) of vertical space
2.0 inches (15.0 centimeters) behind and to the sides of the IP690 to allow the exit fans to
move air through the appliances
Caution
Do not block the ventilation holes on the IP690. The appliance might overheat and
become damaged.
Other Specifications
Maximum altitude of operation
Operating temperature range
Input voltage requirement
Current
Power consumption
Check Point IP690 Security Platform Installation Guide
Height:
1.7 in. (43.4 cm)
Width:
17.0 in. (43.2 cm, without mounting
bracket)
19.0 in. (48.3 cm, with mounting bracket)
Depth:
24.9 in. (63.2 cm) including front bezel
25.4 in. (64.5 cm) including front handles
12.4 kg (27.3 lbs)
To 10, 000 feet or 3300 meters above sea
level
°
41 to 104
Fahrenheit
°
5 to 40
Celsius
100 VAC or 240 VAC, 50 or 60 Hz
4A
250 watts per power supply
109
