Replacing Check Point TE1000X

Appliance Hard Disk Drives

706306

Protected

2015

Important - Make certain that you are electromagnetically grounded

when performing the following procedures. Static electricity can damage

the appliance.

Item

Description

Release latch

Extraction handle

For a list of our Third Party Copyright notices, please refer to:

Classification [Protected]

For a list of our trademarks, please refer to: http://www.checkpoint.com/copyright.html.

http://www.checkpoint.com/3rd_party_copyright.html

P/N:706306 | 1

Table of Contents

Need help?

Do you have a question about the SandBlast TE1000X and is the answer not in the manual?

Page 1 Extraction handle Classification [Protected] P/N:706306 | 1 © 2015 Check Point Software Technologies Ltd. All rights reserved. For a list of our trademarks, please refer to: http://www.checkpoint.com/copyright.html. For a list of our Third Party Copyright notices, please refer to: http://www.checkpoint.com/3rd_party_copyright.html...
Page 2 Removing a Hard Disk Drive To remove a hard disk drive: Using the key supplied in the toolkit, unlock the drive. Slide the release latch toward the left. The extraction handle pops out. Using the extraction handle, remove the drive from the slot carefully. Installing a Hard Disk Drive To install a hard disk drive: Slide the replacement hard disk drive into the slot.
