Ribbon Cassette Handling Precautions; Replacing The Paper Roll - Epson TM U200D - B/W Dot-matrix Printer Technical Manual

Ribbon Cassette Handling Precautions

Use only the ribbon cassette specified in Chapter 1 of this manual. If another ribbon cassette
is used, any of the following may occur:
Print quality deterioration
Printer life may be shortened
Ink may leak
The ribbon may catch on the print head.
Do not re-ink a ribbon. If a ribbon is re-inked:
Print quality could deteriorate due to a malfunction of the print wires
Ink may leak.

Replacing the Paper Roll

Note:
Be sure to use roll paper that meets the specifications.
1. Turn on the printer.
2. Remove the Cover, printer.
3. Pull the paper and cut the paper at the dotted line shown in the illustration below.
4. Press the FEED button to remove the cut paper.
5. Remove the used paper roll.
3-2 Handling and Maintenance
Cut here
Rev.B
