3 Select a database from the Keynote Database list.
4 Select the root node for the database if you want to add a top-level group, or expand the root node and
group/subgroup nodes as necessary until you can select the node to which you want to add a subgroup.
5 Click .
The Add Group dialog box is displayed with the read-only ID field showing the database identifier for the
group you are adding.
6 Enter a Group Name and a Description, and click OK.
The group or subgroup you have defined is displayed as a new node in the hierarchical tree view.
Adding Keynotes to a Keynote Database
Use this procedure to add a keynote to a group or subgroup within a keynote database.
1 On the Window menu, click Pulldowns
2 On the CAD Manager menu, click Keynote Editor.
NOTE The rest of this procedure can also be performed from the Select Keynote dialog box.
3 Select a database from the Keynote Database list.
4 Expand the root node and group/subgroup nodes as necessary until you can select the node to which you
want to add a keynote.
5 Click .
The Add Keynote dialog box is displayed with the read-only ID field showing the database identifier for
the keynote you are adding.
6 Enter a key and a note, and click OK.
The keynote you have defined is displayed as a new node in the hierarchical tree view.
CAD Manager Pulldown.
Working with Keynote Databases | 1977
