7 Add the tape cartridges to the library's modules using the I/E station commands from the operator panel
or web client.
8 If the host application inventories the location of each tape cartridge in the library, open the host
application and reinventory in order to sync its logical inventory with the physical inventory of the library.

Replacing a 9U Expansion Module

These instructions explain how to remove and replace a 9U expansion module. You may need to replace
the 9U expansion module if its chassis is severely damaged.
The 5U library firmware supports the addition of one 9U expansion module to a
Note
maximum height of 14U.
ALL LIBRARIES MAY BE INSTALLED IN A RACK HAVING A MAIN
WARNING
PROTECTIVE EARTHING (GROUNDING) TERMINAL, AND POWER
MUST BE SUPPLIED VIA AN INDUSTRIAL PLUG AND
SOCKET-OUTLET AND/OR AN APPLIANCE COUPLER COMPLYING
WITH IEC 60309 (OR AN EQUIVALENT NATIONAL STANDARD) AND
HAVING A PROTECTIVE EARTH (GROUND) CONDUCTOR WITH A
CROSS SECTIONAL AREA OF AT LEAST 1.5 MM
TO ENSURE PROPER AIRFLOW AND ACCESS SPACE, ALLOW 60 CM
(24 INCHES) IN THE FRONT AND BACK OF THE LIBRARY.
WITHOUT TAPE DRIVES, TAPE CARTRIDGES, OR POWER
WARNING
SUPPLIES, A 5U WEIGHS APPROXIMATELY 58 LBS. A 9U , WITHOUT
TAPE DRIVES, TAPE CARTRIDGES, OR POWER SUPPLIES,
EXCEEDS 65 LBS.
TO AVOID SERIOUS INJURY, AT LEAST TWO PEOPLE ARE
REQUIRED TO SAFELY LIFT THE MODULES INTO POSITION.

Preparing to Remove the 9U Expansion Module

Required tools:
• Phillips #2 screwdriver, for removing and replacing the top cover plate
• T10 TORX screwdriver, for removing and replacing the bottom cover plate
1 Power off the library.
2 Disconnect all power cords, network data cables, and module-to-module cables from each module you
will be removing.
You should label all cables before you remove them so you can later
Note
reconnect them to their proper locations.
3 Remove all power supplies from each module that you intend to remove. For details, see
Removing, and Replacing Power Supplies
Tandberg StorageLibrary T128 User's Guide
on page 136.
2
(14 AWG).
Adding,
123
