Electrical Specifications

Library Power Consumption and Heat Output

Table 20 lists the typical library power consumption (Watts) and heat output (BTU/hr).
page 171 shows the typical and maximum library power consumption (Watts) and heat output (BTU/hr), and
Figure 17 on page 171 shows the library typical and maximum power draw.
Table 20 Library Typical Power Consumption and Heat Output
Library Configuration
Subassembly Power Consumption:
Tandberg StorageLibrary T128
and LCB
UDS3 IBM Ultrium 2 Drive Sled Module (SCSI)
UDS3 IBM Ultrium 2 Drive Sled Module
(Fiber Channel)
UDS3 IBM Ultrium 3 Drive Sled Module (SCSI)
UDS3 IBM Ultrium 3 Drive Sled Module
(Fiber Channel)
Control Module:
Minimum (1 drive)
Maximum (2 drives)
Expansion Module:
Minimum (no drives)
Maximum (4 drives)
170
Typical Power
Consumption (Watts)
Library with Robot 65
29
32
27
29
97
129
0
193
Figure 16 on
Typical Heat
Output
(BTU/Hour)
222
99
109
92
97
331
440
0
659
Specifications
