Figure 7 SCSI Interface —
Terminator Installation
DLT-V4 Product Manual
Terminator
SCSI cable
If the SCSI cable that came with the SCSI host adapter already
Note:
has a terminator built into it, do not use another terminator.
Figure 8
shows an example of such a cable.
Chapter 2 Installing the Tape Drive
Installing the Internal SCSI Tape Drive
18
