Tandberg Data DAT320 Quick Start Manual

DW090-90901 Tandberg DAT320 SAS Int Eng front.pdf
Tandberg Data DAT320 SAS
Internal Tape Drives
C
M
Y
CM
MY
CY
CMY
K
Printed on at least 50% total recycled fiber with at least 10%
post-consumer paper
© 2009 Tandberg Data
Printed in the EU
www.tandbergdata.com
Part No. 1018928
DW090-90901
11/9/09 10:32:11
Introduction
1
This poster describes how to install your Tandberg Data DAT320 tape drive.
• Use the fixing screws supplied with the tape drive
• Is connection to your SAS server supported?
• Can you connect to the host SAS controller or do you need to purchase an
additional HBA?
WARNING: To avoid personal injury or damage to the server or tape drive,
disconnect your server from the mains power supply before installing the tape
drive.
To avoid damage to server or tape drive observe all recommended anti-static
and power-grounding precautions, as specified in your server and tape drive
manuals.
Other sources of information
2
There is a more detailed "User Guide" on www.tandbergdata.com.
If you need technical support or have any problem with your DAT320 tape storage
solution, please visit the support pages at www.tandbergdata.com.
Preparing the host
3
IMPORTANT: Refer to www.tandbergdata.com
information about operating systems and software applications.
SAS cable and port
A standard SAS cable (not supplied) with integrated power connector is appropriate
for this installation. The server must have a SAS HBA that supports internal SAS
ports. See www.tandbergdata.com for recommended products. If necessary, install
a new HBA and any associated drivers before you install the tape drive.
Drivers
For Windows systems, download the latest drivers from www.tandbergdata.com.
For other operating systems, patch to the latest version of the operating system,
following the instructions in the patch documentation.
Backup software
Always upgrade your software application to ensure it works correctly with the tape
drive. We do NOT recommend native backup applications, such as Windows Backup,
because they do not support the full features of the tape drive and may cause
performance problems.
NOTE: Some backup applications require you to use their own drivers. Refer
to the documentation of your software application to ensure you are using the
recommended driver.
Hardware encryption
The DAT320 tape drive includes hardware capable of supporting data encryption.
To make use of this feature you need a backup application that supports hardware
encryption and DAT320 media.
Power requirements
Voltage Typical Current
5 V 0.7 A
12 V 0.25 A
Mounting bay
You need one industry-standard, 5 1/4-inch, half-height bay in which to install the
Tandberg Data DAT320 tape drive.
Different models of server require different mounting methods. Refer to your server
documentation for detailed information. You may need to purchase mounting
hardware separately.
for detailed compatibility
Maximum Current
1.4 A
1.3 A
