Connecting The Scsi Interface Cables; Figure 2 Scsi Id Selector Switch - Tandberg Data DLT-V4 Product Manual

Figure 2 SCSI ID Selector
Switch
Connecting the SCSI
Interface Cables
DLT-V4 Product Manual
In the final installation stage, you connect the SCSI and power cables to
the tape drive.
2
If the selected server or workstation does not already have an
Note:
installed SCSI host adapter, you will need to install one. For
more information on SCSI host adapter requirements, see
Bus Requirements
To connect the SCSI and power cables to the tape drive, follow these
steps:
Shut down the operating system and power down the server or
1
workstation.
Power off all peripheral devices, such as printers and other SCSI
2
devices.
Caution:
Obtain a SCSI cable with an open 68-pin, high-density connector.
3
Connect one end of the SCSI cable to one of the connectors on the rear
4
panel of the tape drive as shown in
works equally well.
none of the three tape drives in the illustration are at the end of the
SCSI bus.
Installing the Tabletop SCSI Tape Drive
Press here to decrease
SCSI ID
Press here to increase
SCSI ID
on page 4.
Do not go to step 3 until you have completed steps
and 2. Failure to follow these instructions may result
in damage to the tape drive or other devices.
Figure 3 does not show a terminator because
Chapter 2 Installing the Tape Drive
figure 3. Either SCSI connector
SCSI
1
9
