Keyboard Area - Gateway C-140S Reference Manual

Component Icon
Battery latch
Main battery
Battery lock
Hard drive
bay
Pen latch
Digital pen

Keyboard area

Tablet control buttons/Status indicators
Microphone
Keyboard
Optional
fingerprint
reader
10
CHAPTER 2: Checking Out Your Notebook
Description
Slide to release the main battery. For more
information, see
Provides power when the convertible notebook is not
plugged into AC power.
Slide to unlock the battery. For more information, see
"Changing batteries" on page
The hard drive is located in this bay. For more
information, see
page 110.
Slide to release the digital pen.
Write, tap, and input directly on your convertible
notebook's display using the digital pen.
Touchpad
"Changing batteries" on page
69.
"Replacing the hard drive kit" on
Power button
69.
Power
button
lock
