Gateway C-140S Reference Manual page 117

www.gateway.com
11
Pull the memory module out of the slot.
12
Hold the new or replacement module at a 30-degree
angle and press it into the empty memory slot. This
module is keyed so it can only be inserted in one
direction. If the module does not fit, make sure that the
notch in the module lines up with the tab in the memory
bay.
13
Replace the memory bay cover, then replace the cover
screw.
14
Insert the main and optional multibay batteries, then
turn your convertible notebook over.
15
Connect to the optional port replicator.
-OR-
Connect the power adapter, modem cable, and network
cable.
16
Reconnect all peripheral devices and replace any
PC cards.
109
