General information

Features and specifications

© Copyright IBM Corp. 2000
Your Netfinity 4500R server is a high-performance server that supports symmetric
multiprocessing (SMP). It is ideally suited for networking environments that require
superior microprocessor performance, efficient memory management, flexibility, and
large amounts of reliable data storage.
Performance, ease of use, reliability, and expansion capabilities were key
considerations during the design of your server. These design features make it
possible for you to customize the system hardware to meet your needs today, while
providing flexible expansion capabilities for the future.
Your IBM Netfinity 4500R server comes with a three-year limited warranty and IBM
Server StartUp Support. If you have access to the World Wide Web, you can obtain up-
to-date information about your server model and other IBM server products at the
following World Wide Web address: http://www.ibm.com/pc/us/netfinity/
The following table provides a summary of the features and specifications for your
Netfinity 4500R server.
Microprocessor:
• Intel® Pentium III
• 256 KB Level-2 cache
• Supports up to two microprocessors
Memory:
• Maximum: 4 GB
• Type: ECC, SDRAM, Registered DIMMs
• Slots: 4 non-interleaved
Drives standard:
• Diskette: 1.44 MB
• CD-ROM: 24X IDE
Expansion bays:
• Hot-swap: 3 slim high
• Non-hot-swap: Two 5.25-inch
PCI expansion slots:
• Three 33 MHz/64-bit
• Two 33 MHz/32-bit
Hot-swap power supplies:
• 270 Watt (115-230 Vac)
• Minimum: One
• Maximum: Two, second power supply provides redundant power
Redundant cooling:
• Three hot-swap fans
