Video port

Your server comes with an integrated super video graphics array (SVGA) video
controller. This controller is not removable, but you can disable it by installing a PCI
video adapter.
Note: If you install a PCI video adapter, the server BIOS will automatically disable
the integrated video adapter.
The following table shows the pin-number assignments for the 15-pin analog video
connector on the rear of your server.
Table 11. Video-port connector pin-number assignments.
Pin
1 Red
2 Green or monochrome
3 Blue
