Post Error Codes - IBM Netfinity 4500R Type 8656 Hardware Maintenance Manual

AC Good LED DC Good LED
On Off
On On

POST error codes

122
Hardware Maintenance Manual: Netfinity 4500R Type 8656
Description
Standby mode or dc
problem.
Power is OK.
In the following error codes, X can be any number or letter.
Error Code/Symptom
062
consecutive boot failures using
the default configuration.)
101, 102 (System and
processor error)
(System and
106
processor error)
111 (Channel check
error)
114 (Adapter read-only
memory error)
129 (Internal cache
error)
1. Check system board cable connectors J4
and J15 that go from the Planar to the
Power Backplane. Set the Power-On
Override Switch, which is switch 5 of
SW1m to the ON position. See "System
board switches and jumpers" on page 42.
Note:
If the good LED comes on, the problem
could be:
a.
b.
2. Remove the adapters and disconnect the
cables and power connectors to all internal
and external devices. Power-on the system.
If the DC Good LED comes on, replace the
adapters and devices one at a time until you
isolate the problem.
3. Power Supply
4. Power Backplane
5. System Board
N/A
(Three 1.
Run Configuration/Setup
2. Battery
3. System Board
4. Processor
1. System Board
1.
System Board
1. Failing 15A adapter
2. Memory Dimm
3. System Board
1. Failing Adapter
2. Run Diagnostsics
1. Processor
2. Optional Processor (if installed)
3. System Board
FRU/Action
Power-On Override Switch is
for problem determination
purposes only. Use of this
switch will cause POST errors.
Power Switch Assembly
System Board
FRU/Action
