2.11 WHEELS AND TIRES

Inspect the tire surfaces for cuts, nails or other sharp objects.
Check the each tire surface at cold tire condition.
*The standard of tire pressure is 12(0.8) psi ( kgf/cm2)
STEERING SHAFT HOLDER BUSHING
Remove the front fender first.
Remove the steering shaft holder and check the steering shaft bushing
for wears or damage.
If the bushing is worn or damaged, please change a new one.
Grease the steering shaft bushing and install the parts
in the reverse order of removal.
Torque: steering shaft holder bolt: 33 N.m (24 lbf.ft)

2.13 TOE-IN

Keep the vehicle on level ground and the front wheels facing straight
ahead.
Mark the centers of the tires to indicate the axle center height.
Measure the distance between the marks.
Carefully to move the vehicle back, let the wheels turn 180 degree,
so the marks on the tires are aligned with the axle center height.
Measure the distance between the marks.
Calculate the difference in the front and rear measurements.
Toe-in: 5±10mm
