UDM 35/40 PANEL METER USER MANUAL
Press and hold for 2 seconds. Display will indicate PASS (password). Within
2 seconds, four zeros "0000" will be displayed. This is your prompt to enter your
password. If zero "0000" is your password, simply press
have approximately 20 seconds to begin programming before the unit reverts
back to run mode. (To enter a unique password, see Access to Programming
Mode, above.)
Input Selection
Press the key once to advance to Input
When the TRX module is installed, you must first indicate probe choice:
TRX input modules offer three Probe (Prob) choices: thermocouple* (tc),
RTD (rtd), plus resistive (rES). Use
Press . Use
to table below and on instruction sheet. Press
Programming the Input Modules
or
keys to select Range (r1, r2, r3, r4, r5, r6) according
to confirm. You
keys to make selection.
.
5
