UDM 35/40 PANEL METER USER MANUAL
The UDM 35/40 series is a universal Digital Panel Meter that has been
developed to meet the most advanced application requirements. The UDM 35
offers:
•
Quick assembly and maintenance using plug & play modules
•
Quick & easy parameter programming and parameter cloning to
other UDMs by means of UDMSoft or PC HyperTerminal
•
Powerful variable control by means of up to four (4) alarm outputs
•
Alarms can be up-down functions with automatic reset, up-down
with manual reset, and down alarm with disable function at power-
up.
The UDM 40 offers the same features as the UDM 35, with the following
additional benefits:
•
Display color adaptable to Green, Red and Amber
•
Management of non-linear signals using the available 16-point
linearization capability
•
"Alarm status at a glance" using a sequence of display colors that
can be programmed by the user
UDM Description
2
