MAX-MDL200 Multi-Disc Loader System
Disc Loading Slot
(insert discs
here to load the
internal carousel).
Power button
FIG. 2 MDL200 Multi Disc Loader
When used with the laptop PC that comes with it (pre-configured with the BulkRipper
application), there is no need to use the front-panel controls on the MDL200. Instead,
use the controls provided in the BulkRipper application as described in this manual.

MDL200 Product Specifications

MDL200 (FG 2179-01) Specifications
Storage Capacity:
Power Requirements:
AC Current Draw (AMP):
Interface Specifications
(IEEE 1394):
Number of Drives:
2
(front)
(rear)
IEEE 1394 ports
200 discs, 4.7 GB/disc
• Voltage: 110 – 240V AC (autosensing)
• Frequency: 50/60 Hertz
• Consumption: 45 watts (peak), 35 watts (normal)
• .45A - Bootup/Power Cycle Peak
• .45A - Normal Usage Peak
• Bus interface IEEE-1394 compliant
• Data transfer rate 100, 200, and 400Mbps
• Three 6-pin IEEE-1394 ports
Two DVD-ROM drives (both drives can transfer disc images
simultaneously)
front panel controls (see Note below)
Power cable connector
MAX-MDL200 Multi-Disc Loader System
