Additional Notes On Loading Discs - AMX MAX-MDL200M MULTI DISC LOADER Instruction Manual

Using BulkRipper and the MDL200
The Changer > Load Range and Load All options operate the same, except that
Load Range allows you to specify a range of slots to load (in the Start Disc/End Disc
fields).
3. This prompts the MDL200 to present each open slot on the disc carousel so that you can load a
disc into each one. If there are already some discs loaded in the carousel, the MDL200 will
automatically skip any slot positions that are already occupied and present the next open slot
for loading.
You will hear the MDL200's internal carousel spin to the next available empty slot and stop. At
this point you have approximately 10 seconds to insert a disc.
Note that at this point the discs that have been loaded are indicated on the BulkRipper main
screen, but without any title or media information since they have not yet been identified by the
program (FIG. 10).
FIG. 10 BulkRipper indicating that discs have not yet been identified

Additional Notes on Loading Discs

The MDL200 features two DVD-ROM drives which can be used simultaneously. There are several
possible ways to take advantage of this feature:
10
A silk-screen below the Disc Slot indicates the proper orientation of the disc: the label
side of the disc must always face to the right.
Discs must be clean and without any labels that could come off during the transfer
process.
For best results, always load discs into the MDL200 contiguously, avoiding leaving
empty slots within a range of occupied slots.
Keep the disc cases in the order that you loaded the discs to make the unloading process
easy.
MAX-MDL200 Multi-Disc Loader System
