AMX BulkRipper - Program Reference

Disc/Slot Window

The main element in the BulkRipper application window is the Disc/Slot Window (FIG. 17). This
window is a table, where each row represents a corresponding disc slot in the MDL200 (therefore,
200 rows).
FIG. 17 Disc/Slot Window
This table contains several columns and uses color-coding to indicate status, as described below:
24
• Cur Disc:
• Drive Status Bars:
Disc/Slot numbers (1-200)
Disc titles
Checkmarks indicate which discs have been identified and are ready for transferring.
Checkmark = the disc in this slot has been successfully identified or transferred.
No Checkmark = disc has not been identified, or there was some other error, as indicated in the
Status column.
• Checkmarks: Checkmarks indicate which discs have been identified and are ready for
transfer.
• Checkmark = the disc in this slot has been successfully identified or transferred.
• No checkmark = disc has not been identified, or there was some other error, as
indicated in the Status column.
Note that the checkmarks for all slots in the range being transferred are cleared
when the transfer process begins.
• Disc column: This column indicates the number of each slot in the MDL200 disc carousel
(1-200).
• Title column: This column indicates the title of the disc that occupies this slot number, once the
disc has been identified.
• Type: This column indicates the type of media loaded in this slot (DVD-ROM or
CD-ROM).
This field displays the slot number of the disc that is currently being
identified or transferred in this drive (1-200).
The status bars indicate the current status of each of the MDL200
DVD-ROMs. Text messages displayed in the Disc/Slot window
(Status column) offer additional status information (see following
section).
Number of title matches found when the disc was identified
Disc Status (Identified or Error)
Disc type (CD or DVD)
