Using BulkRipper and the MDL200
Example back cover of
a typical DVD case
FIG. 13 Finding the UPC Code on a DVD or CD case

Verifying Disc Information

In some cases in which the program has indicated more than one possible match for a disc, it may
not be obvious which of the possible matches represents the best match for the disc. In these cases
you should eject the disc momentarily so that you can visually check the physical label on the disc.
The Eject and Load buttons on the Multiple Matches dialog allow you do this quickly:
1. Double-click on the disc/slot in question (in the Disc/Slot Window) to access the Multiple
Matches dialog (FIG. 12). Review the list of possible title matches in this dialog.
2. Click on the Eject button in the Multiple Matches dialog. This option ejects the disc from the
MDL200. Remember that you have approximately 10 seconds to remove the disc from the slot.
Note that by using the Eject and Load buttons in the Multiple Matches dialog, the
program retains any disc information that exists for this disc.
This is also true for the Load and Eject buttons in the New Title Entry dialog (see
FIG. 14).
By contrast, if you eject a disc from the MDL200 via the Eject options in the Changer
menu, or the Disc Context Menu, all disc information is lost. These options are
intended to be used at the point that the disc is being permanently removed from the
MDL200, once the loading process is complete.
3. Look at the disc label to discern which of the possible title matches best matches this disc.
4. Press the Load button in the Multiple Matches dialog, and replace the disc in the Disc Loading
Slot.
5. Select the best possible match in the Multiple Matches dialog and click OK.
Do not close the Multiple Matches (or New Title Entry dialog) until the disc has been
reloaded. If the dialog is closed while the disc is still ejected, the slot will be set to
<empty>, and all disc information will be lost.
14
UPC codes are unique 12-digit catalog
numbers that identify a particular item.
They can usually be found on the back cover
of the DVD or CD case.
Make sure you include any smaller numerals that
appear to the left or right of the main barcode numerals.
In this example the UPC code is "097360962925".
MAX-MDL200 Multi-Disc Loader System
