MAX-MDL200 Multi-Disc Loader System
Troubleshooting Ethernet Communications Problems
lights when receiving data packets
FIG. 8 Ethernet port LEDs
8
The Link (L) LED next to the Ethernet port on the MMS server should be on (FIG. 8). If
not, check your cables and connectors.
A - Activity LED
Verify that the IP address and Subnet Mask settings are appropriate for your network
configuration.
If you are connecting to the server via a direct connection with a PC (using a crossover
Ethernet cable), be sure that the IP Address of the Network card in your PC is in the same
range as the server, but not the same address as the server.
For example, a network card setting of 192.168.1.31 will work with the default server IP
address of 192.168.1.30.
L - Link LED
lights (full-on when the Ethernet cables
are connected and terminated correctly
MAX-MDL200 Multi-Disc Loader System
