Verifying Communication Between the PC, MDL200 and
MMS Server
Once the MDL200, laptop PC and MMS server are connected and powered up:
1. Launch the BulkRipper application on the laptop PC (double-click the BulkRipper desktop
icon to launch the program and access the main window).
Status Bar
Indicates whether the MDL200 is
connected to the laptop and running
FIG. 6 BulkRipper Status Bar
2. The laptop PC and the BulkRipper application are pre-configured to allow communication
between the PC, the MDL200 and the MMS. The status bar (at the bottom of the dialog)
should indicate that you have successfully connected to the MDL200 and the MMS server (see
FIG. 6):
The center area of the status bar should indicate that the MDL200 (Powerfile-C200) is
connected and running, and the MMS icon on the right side of the status bar should be green to
indicate communication with the server.
If you are not communicating with either the MDL200 or the MMS server, first verify that your
cables are connected properly. Then select File > Settings (in BulkRipper) to open the Settings
dialog (FIG. 7):
FIG. 7 Settings dialog (select File > Settings to open)
Verify that the Max MMS/IMS IP address indicated here matches that of the target MMS
server.
3. Click OK to save your changes and close the Settings dialog.
Once the status bar indicates that you are connected to both the MDL200 and the MMS server, then
you are ready to load discs (DVDs and CDs) into the MDL200.
Refer to the Using BulkRipper and the MDL200 section on page 9 for instructions on using
BulkRipper and the MDL200 to load, identify and transfer discs to the target MMS server.
MAX-MDL200 Multi-Disc Loader System
MAX-MDL200 Multi-Disc Loader System
Indicates whether the laptop is connected
and communicating with the MMS server
Enter IP Address of the target MMS Server here
