Loading Media to the Target MMS Server

Once all of the disks have been loaded into the MDL200, you are ready to load DVD and CD media
to the MMS server.

Step One: Verify the Transfer Settings

Before you start, select File > Settings to open the Settings dialog (FIG. 11) and set the Record
discs with multiple matches option to the desired setting:
FIG. 11 Settings dialog
MAX-MDL200 Multi-Disc Loader System
Once you have loaded 200 discs into the MDL200, you can specify a separate range of
discs on the two drives. For example, to load 200 discs, you could assign discs 1-100 to
Drive 1 and discs 101-200 on Drive 2.
Since you configure each of the DVD-ROMs independently, you can take advantage of
the fact that they each be set to a different region code. For example, if you intend to load
a large number of DVDs with multiple region codes, consider setting different region
codes on the two drives to accommodate the majority of DVDs/region codes in the set.
Since you can specify which drive you load each movie to, you could reduce the number
of times you would have to change the region code settings. In effect, having two DVD-
ROMs in the MDL200 allows you to make up to a total of 10 region code setting
changes, even though the standard limit of five changes per DVD-ROM is still
hardware-enforced.
If set to Yes: Discs that were not positively identified will be transferred. As a result,
these discs will not have any disc information associated with them.
If set to No: This option causes the MDL200 to skip transferring any discs that have
multiple title matches, or that are not positively identified. These discs can later be
identified manually, by transferring the same range of discs again. Since BulkRipper will
not attempt to transfer any disc that has already been marked as transferred, it will only
transfer the discs that were manually identified.
This is the default (and recommended) setting.
Using BulkRipper and the MDL200
Enter IP Address of the target MMS Server here
Specify a transfer option
11
