Manually Entering Disc Information

If no suitable title matches are found, then you may enter the information manually via the New
Title Entry dialog (FIG. 14):
Disc slot number (1-200) and
media type (CD or DVD)
FIG. 14 New Title Entry dialog (for DVDs)
1. Click New Entry in the Multiple Matches dialog to open the New Title Entry dialog. This
dialog contains a text field where you can manually enter a title for this disc. For DVDs, you
can also associate a Genre, Aspect Ratio and Sound option to the disc.
If necessary. you can use the Eject and Load buttons in the New Title Entry dialog to eject the
disc so that you can review any information that is printed on the disc label:
a. Press Eject to eject the disc (at which point you have approximately 10 seconds to
physically remove the disc from the disc loading slot on the MDL200).
b. When you're finished, press the Load button and replace the disc (label-side facing to the
right) in the carousel (you have 10 seconds after pressing the Load button to insert the
disc).
2. Click inside the Title text field, and type the title that you want to associate with this disc.
3. For DVDs, use the drop-down menus to select a Genre, Aspect Ratio and Sound option, and
click OK to accept the new disc information.

Identifying Discs - Without Transferring Media

The MDL200 can be used to identify loaded discs without performing the transfer function. To
identify the discs loaded in the MDL200:
1. Specify a range of discs to be identified, using the First Disc and Last Disc fields (on the
BulkRipper main screen) for each drive.
2. Click the Identify button.
BulkRipper uses color coding to indicate whether each disc has been successfully identified
(see the Disc/Slot Window section on page 24 for details).
MAX-MDL200 Multi-Disc Loader System
Type disc title here
Ejects this disc from the MDL200
Press to load a disc into this slot number
Using BulkRipper and the MDL200
15
