Programming
Border Styles and Programming Numbers
No. Border styles
0 No border
1 No border special
2 Single line
3 Double line
4 Triple line
5 Single rounded
6 Double rounded
7 Single raised
8 Double raised
9 Triple raised
10 Double-line two single

Shorthand Send_Commands

The table below lists the shorthand Send_Commands you can use with touch panels. The shorthand
command data is 1-byte, non-ASCII format except for pages, passwords, text, and bitmap names.
Shorthand Send_Commands
@CBF
Sets the OFF
feedback border
color to the speci-
fied color.
@CBN
Sets the ON feed-
back border color
to the specified
color.
28
Border styles can be used to program borders on buttons, sliders, and gauges.
No.
11
20
21
22
23
24
25
26
27
40
41
This works only if the specified background color is not the same as the current color.
Syntax:
"'@CBF',<variable text address>,<color_number>"
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 27.
Example:
SEND_COMMAND TP,"'@CBF',1,0"
Sets the OFF feedback border color to Red for the variable text button 1.
This works only if the specified background color is not the same as the current color.
Syntax:
"'@CBN',<variable text address>,<color_number>
Variables:
variable text address = 1 - 255
color number = See the Colors and Programming Numbers table on page 27.
Example:
SEND_COMMAND TP,"'@CBN',2,78"
Sets the ON feedback border color to Gray for variable text button 2.
Border styles
Double shadow
3-dimensional rectangle 1
3-dimensional rectangle 2
3-dimensional round 1
3-dimensional round 2
3-dimensional neon 1
3-dimensional neon 2
3-dimensional neon blue
3-dimensional neon green
Single diamond
Double diamond
AXP-PLV PosiTrack Pilot Video Camera Controller
