This document describes AXlink, wiring topologies, electrical timing and characteristics, compatible cable types, wiring distance calculations, and wiring diagram examples. AXlink is a proprietary communication protocol designed by AMX to control up to 255 devices with a Central Controller using common copper conductors. -
Page 6: Axlink Electrical And Timing Characteristics
AXlink Wiring Considerations AXlink Electrical and Timing Characteristics FIG. 2 shows the electrical and timing characteristics of AXlink. The table below describes each characteristic. FIG. 2 AXlink electrical and timing characteristics Electrical timing characteristics Parameter Description Min. Typical Max. Units... -
Page 7: Power Distribution
Central Controller and external AXlink devices. Most power supplies are factory set to 13.5 VDC. Never use a power supply that exceeds 18 VDC for remote or local power configurations. Contact AMX for a complete list of products and their power consumption ratings. -
Page 8: Liberty Cable & Wire Inc. Cables
Central Controller and all external devices is 3,000 feet with no remote power. FIG. 4 shows a wiring diagram for the AMX-approved Belden 8102 AXlink cable. The PWR connection shown in the wiring diagram is only used when supplying 12 VDC via the AXlink cable. -
Page 9: Using Ground Shielding
