Bounding rectangle (0x02)
Specification by data type:
Description of data:
Size of data in bytes:
Example:
Note:
CMYK color definition (0x03)
Specification by data type:
Description of data:
Size of data in bytes:
Example:
Note:
RGB color definition (0x04)
Specification by data type:
Description of data:
Size of data in bytes:
Metric, metric, metric, metric
Position of graphic (metric, metric)
Width of graphic (metric)
Height of graphic (metric)
16
02 00000010 00000000 00000000 020A0000 00BD0000
for a graphic with the following specifications:
x position = 0 points (0000)
y position = 0 points (0000)
width = 522 points (020A)
height = 189 points (00BD)
This must be the second op code for a FrameVector graphic.
String, metric, metric, metric, metric
Name of color tag (string)
Percentages of cyan, magenta, yellow, and black (metric, metric, metric, metric)
Variable
03 0000001B 00 0B 53 61 67 65 20 47 72 65 65 6E 00 00500000 00230000 00320000
00000000
for a color named Sage Green with the following specifications:
cyan = 80% (0050)
magenta = 35% (0023)
yellow = 50% (0032)
black = 0% (0000)
See "Definition op codes" on page 291 for more information on color definitions.
String, metric, metric, metric
Name of color tag (string)
Percentages of red, green, and blue (metric, metric, metric)
Variable
ADOBE FRAMEMAKER 6.0 294
FrameVector Facet Format
