11 Appendix
BIOS Information
Background I/O's
Due to memory manipulation done during the PCI configuration cycle, background I/O's on the
Intel RAID Controller SRCU31 cannot be run until the OS is up and running.
BIOS Boot Messages
When booting the Intel RAID Controller SRCU31, the boot message in Figure 111 appears. In this
example, an Intel RAID Controller SRCU31 has been detected in PCI slot 3, and it has 32 MB of
RAM installed on the controller. A detailed explanation of the boot message follows.
Figure 111. BIOS Boot Message
179
