- Page 1 PC VGA WUXGA to Video Converter ID #15015 Operation Manual...
- Page 2 Introduction PC VGA WUXGA to Video Converter is a PC computer to PAL or NTSC interlaced video converter which has new expanded input acceptance for PC resolutions, now up to WUXGA@60RB (1920*1200). Downscale standard and high resolution PC signals to standard definition interlaced PAL or NTSC video for interfacing with older style Composite or Super-Video input monitors and TV's.
- Page 3 Operation Controls and Functions Top Panel 1.POWER & LED Press this button to switch ON the device and the LED will illuminate in green or set it to standby mode and the LED will turn red. Front Panel PC INPUT Connect the VGA input port to the VGA output port of your source equipment such as computer with D-Sub 15pin cable.
-
Page 4: Video Out
Rear Panel S-VIDEO OUT Connect the S-Video output port to the S-Video input port of analog monitor, Projector or TV. VIDEO OUT Connect the Composite Video output port to the Composite Video input port of analog monitor, Projector or TV. UNDERSCAN /OVERSCAN Switch in between the Underscan/Overscan of the output image especially when connecting to different monitor/TV. - Page 5 Specifications Input port 1 x VGA Output ports 1 x Composite, 1 x S-Video Input Resolution PC: 640x480 = VGA@60, 72, 75, 85 720x400@70, 576p, 800x600 = SVGA@56, 60, 72, 75, 85 1024x768 = XGA@60, 70, 75, 85 1152x864 = MAC@70, 75, 85 720p@25,30,50,60,60cvt 1280x768 = WXGA@60RB, 60 1280x800 = WXGA@60RB, 60, 75...
- Page 6 Connection...
