- Page 1 Multi-format to HDMI scaler #15107 Operation Manual...
- Page 2 Introduction The Digital Video Scaler has CV, SV, HD, Composite, PC, HDMI and SDI inputs and can scale the signal into HDMI, VGA with audio output ports plus a SDI loop out. This high performance digital video scaler supports HDMI output resolution up to 1080p /WUXGA and Analog Digital Conversion (ADC) &...
-
Page 3: Power & Led
Operation Controls and Functions Front Panel 1. POWER & LED: Press this button to switch ON or set the device to standby mode. Once the device is connected with power supply the LED will illuminate and the device will switch to ON automatically. 2. - Page 4 VGA: Connect to monitor/display for video output display. 2. SERVICE 1: Reserved for factory use only. 3. SDI LOOP OUTPUT: Connect to SDI display or SDI extender for instant SDI input signal display or extending the SDI signal to further area. 4.
-
Page 5: Auto Adjust
7. AUTO ADJUST: 8. OK & ▲▼◄►: Press OK to confirm the selection or press the arrow buttons to scrolled in the OSD selections. RS-232 Protocols ID # 15107 Remote Assignment Assignment ►► ◄◄... - Page 6 RS-232 Commands Command Description Contents Start RS-232 S SOURCE 0~6 Select input source SDI1(0) / HDMI (1) / HDMI2(2) / YPBPR(3) / R SOURCE Inquire input source VIDEO(4) / SVIDEO(5)/ PC(6) S OUTPUT 1~25 Select input source 640*480(1)/800*600(2)/ 1024*768(3)/1280*768(4)/ R OUTPUT Inquire input source 1360*768(5)/1280*720(6)/ 1280*800(7)/1280*1024(8)/...
- Page 7 RAUDIOMUTE Inquire audio mute setting S KEY LOCK 0/1 Key lock setting ENABLE(0) / DISABLE(1) R KEY LOCK Inquire key lock setting Firmware checking S RESET 1 Pre-reset EXIT EXIT Note: iJL command must first be insert before starting using RS-232 command to control the device.
- Page 8 1600x1200 60 1920x1080 60 1920x1200 60 720X480I 60 720X480P 60 1280X720P 60 1920X1080I 60 1920X1080P 60 720X576I 50 720X576P 50 1280X720P 50 1920X1080I 50 1920X1080P 50 DISPLAY(cont) SIZE (VIDEO mode OVER SCAN only) FULL BEST FIT PAN SCAN LETTER BOX UNDER 2 UNDER 1 MODE INFO...
- Page 9 COLOUR COLOUR R OFFSET G OFFSET B OFFSET CONTRAST 0~60 BRIGHTNESS 0~60 0~60 SATURATION 0~60 SHARPNESS 0~30 MIDDLE HIGH AUDIO VOLUME 0~100 DELAY 40mS 110mS 150mS SOUND MUTE SDI AUDIO CH1 - CH2 CH3 - CH4 CH5 - CH6 CH7 - CH8 AUDIO SELECT ANALOG (AV/SV/YPbPr/VGA...
-
Page 10: Specifications
Specifications Input Port 1 x Composite, 1 x S-Video, 1 x Component, 1 x VGA, 2 x HDMI, 1 x SDI, 1 x Optical, 4 x LR , 1 x USB (service only), 1 x HP Jack (service only), 1 x RS-232 (Control Only) Output Port 1 x HDMI, 1 x VGA,... -
