- Page 1 HDMI Enhancer with EDID - ID# 15463 Operation Manual...
- Page 2 Introduction This 4K UHD HDMI to HDMI Enhancer with EDID Management is designed to enhance and stabilize high-bandwidth HDMI signals for cleaner transmission while also providing the utility of customized EDIDs. The built in EDID management support allows the user to easily switch between three distinct EDIDs (Internal, External, and User).
- Page 3 Operating Functions and Controls Front and Rear Panels 1. HDMI IN: Connect to HDMI source equipment such as a media player, game console or set-top box. DVI sources are supported with the use of an HDMI to DVI adapter. Note: 4K UHD sources with HDR or equivalently high-bandwidth signals require an appropriate compatible display and HDMI cables in order to achieve the best image quality.
- Page 4 Side Panel EDID: Press this button to select the EDID to send to the HDMI source. The available choices are: Internal, External, and User. The internal EDID is set to 1080p60 with LPCM 2.0 audio. The External EDID setting passes the EDID directly from the connected display to the source.
- Page 5 detected units will be displayed in the list. Clicking on a detected unit will open the EDID Commander window. EDID Controller Tab Mode Select: The currently selected EDID is displayed here. The “User 1” EDID corresponds to the “Bitstream” setting on the front of the unit. The “User 2”...
- Page 6 • Any EDID from the unit or the connected HDMI display can be saved to your PC as a *.bin file by selecting the EDID source from the drop down menu and then clicking the “Save” icon. • Previously saved EDID files (*.bin format) can be re-uploaded into the unit by selecting the User EDID to replace from the dropdown and then clicking the “Upload”...
- Page 7 and information fields within the EDID file such as Manufacturer Name, Monitor Name, etc. • PC Timing and SD/HD/UHD:These tabs allow for the selection of the resolutions and refresh rates that the EDID will report as supported. • Audio1 and Audio2: These tabs allow for the selection of which audio formats, audio frequencies, channels and speaker locations are supported.
- Page 8 Connection Diagram...
- Page 9 Specifications Video Bandwidth 600MHz/18Gbps Input Ports 1 x HDMI Output Port 1 x HDMI Control Interface 1×USB Micro-B Supported Resolutions 480i@60Hz - 4K@60Hz (4:4:4, 8-bit) VGA@60Hz - WUXGA@60Hz (RB) HDMI Cable Length 15m (1080p@60Hz, 8-bit) 10m (1080p@60Hz, 12-bit) 5m (4K@60Hz, 4:2:0, 8-bit) 3m (4K@60Hz, 4:4:4, 8-bit) Power Supply 5V / 2.6A DC (US/EU standards, CE/FCC/...
- Page 10 Supported PC Resolutions (Hz) Input Output ü ü 640×480@60/72/75/85 720×400@85 ü ü ü ü 800×600@56/60/72/75/85 ü ü 1024×768@60/70/75/85 ü ü 1152×864@75 ü ü 1280×720@60 ü ü 1280×768@60/75/85 ü ü 1280×800@60 ü ü 1280×960@60 ü ü 1280×1024@60 ü ü 1360×768@60 ü ü...
