- Page 1 Video to PC WXGA Upscaler #15014 Operation Manual...
- Page 2 Introduction This is an analog CGA (RGB) or Component (YcbCr) to PC scaler box that can scale to 3 different PC modes of VGA, XGA or WXGA. It enables you to connect your RGB or YcbCr signal source such as game boards or video player to a PC display.
- Page 3 Operation Controls and Functions Top Panel 1. Menu Button: Press this button once to bring out the current input & output information and while the information still appears on screen, press it again to select input signal with RGB or YcbCr. To enter the OSD menu, press and hold this button for 3 seconds.
- Page 4 1. CGA In: Connect the input source equipment such as a PC or video player with a D-Sub 15 pin cable to YPbPr to D-Sub 15 pin cable. 2. DC power supply input. 3. PC output switch: Output resolution selection: VGA 640x480, XGA 1024x768 and WXGA 1366x768, all at 60Hz vertical rate.
- Page 5 Specifications Input Port 1 x D-Sub 15pin female type Input Signal Support Analog-Level Signal RGB 0.7Vp-p 75Ω Hsync/Vsync 2Vp-p ~ 5Vp-p 75Ω YCbCr: Y 1Vp-p 75Ω CbCr 0.7Vp-p 75Ω Input Timing CGA: Hf=15734Hz, Vf=59.94Hz/Non- interlace 480i: Hf=15734Hz, Vf=59.94Hz/Interlace 576i: Hf=15626Hz, Vf=50Hz/Interlace Input format selection RGB / YCbCr Output Timing...
