Step5 Power on the device, and look at the status LED of the slot on the front panel. If the LED stays on after
the card completes initialization, the card is operating normally; if the LED goes off, the card fails the
self-test.

Removing the Mini Card

Follow these steps to remove the mini card, taking the 2GE card for example:
Step1 Power off the UTM device.
Step2 Loosen the captive screws on the mini card with a flat-head screwdriver at the rear of the device.
Figure 7-12 Loose the captive screws
Step3 Pull the mini card out along the guide rails.
Figure 7-13 Uninstall a mini card
Put away the removed mini card in an antistatic bag.
If you are not installing a new mini card in the empty slot, install a blank panel to prevent dust from
entering the chassis. For how to install a blank panel, refer to the "Installing a Blank Panel" section
on page 7-4.
