Intel SR2600URLXNA Spares Parts List & Configuration Manual page 9

Key Optional Accessories:
To enable power supply redundancy – order AXX750WPS
To add PCI-X support – included riser must be replaced with
ASR26XXFHXR
To add support for 6
ASR2500SIXDRV
To add support for SATA Tape Drive – order ASR2500SATAPE
*NOTE: ASR2500SIXDRV and ASR2500SATAPE are installed
in the same bay and can not be installed at the same time.
For complete list of accessories – please reference section 2.
Same as above but with North American power cord
SR2600URSATANA
903802
NA
Intel Server System SR2625UR in base-passive
SR2625URBRP
configuration. Includes:
900989
735858206785
Note(1): To enable SAS drives - add-in SAS adapter is
connector and 2 low-profile x8 connectors)
•
Passive (pass-through, no SAS controller) SATA
Midplane, cabled to SATA ports on motherboard .
SAS drives can be supported by adding discreet SAS
controller.
•
Backplane with proprietary cable-less connection to
Midplane, supporting up to 6 hot-swap SAS/SATA
drives.
•
Bridge board
•
7 DIMM blanks
•
2 processor heatsinks
•
2 hot-swap and redundant capable high-efficient 750W
power supply
•
2 chassis front handles in the box (ears)
th
hot-swap 3.5 inch drive – order
•
Intel Server Board S5520UR
•
Intel Server Chassis SR2625
•
Standard control panel
•
6 2.5" HDD carriers (and filler in slots 7&8)
•
3 fixed, non redundant fans
•
Tape drive bay filler
•
1 full-height riser with three PCI Express 2.0 x8 wired
slots (one x16 connector and two x8 connectors)
•
Passive (pass-through, no SAS controller) SATA
Midplane, cabled to SATA ports on motherboard .
SAS drives can be supported by adding discreet SAS
controller.
•
Backplane with proprietary cable-less connection to
Midplane, supporting 8 hot-swap SAS/SATA drives.
Discrete SAS controller must be added to system to
support SAS drives.
•
Bridge board
•
7 DIMM blanks
•
2 processor heatsinks
•
1 hot-swap and redundant capable high-efficient 750W
power supply
•
2 chassis front handles in the box (ears)
1
1
9
