required. SATA drives can be used in out of the box system.
Key Optional Accessories:
To enable power supply redundancy – order AXX750WPS
To add or change PCI expansion slots – included riser must be
replaced with ASR26XXFHLPR or ASR26XXFHXR
To add support for SATA Tape Drive – order ASR2500SATAPE
For complete list of accessories – please reference section 2.
Same as above but with North American power cord
SR2625URBRPNA
901141
NA
Intel Server System SR2625UR system in SAS
SR2625URLX
configuration. Includes:
900990
735858206792
Key Optional Accessories:
To enable power supply redundancy – order AXX750WPS
To upgrade to full-reatured HW RAID on Active Midplane2:
order Raid key (AXXRAKSAS2) , minidimm
(AXXMINIDIMM512). RAID cache battery backup is optional
(AXXRSBBU3).
To add PCI-X support – included riser must be replaced with
ASR26XXFHXR
To add support for SATA Tape Drive – order ASR2500SATAPE
For complete list of accessories – please reference section 2.
SR2625URLXNA Same as above but with North American power cord
901129
NA
•
Intel Server Board S5520UR
•
Intel Server Chassis SR2625
•
Standard control panel
•
8 2.5" HDD carriers
•
6 redundant and hot-swap fans
•
Tape drive bay filler
•
1 active butterfly riser with five PCI Express 2.0 x8
wired slots (1 full-height x16 connectors, 2 full-height
x8 connector and 2 low-profile x8 connectors)
•
Active cable-less Midplane2 board with 8-port LSI
1078 SAS controller, upgradeable to HW RAID mode
•
Bridge board
•
Backplane with proprietary cable-less connection to
Midplane, supporting 8 hot-swap SAS/SATA drives.
•
7 DIMM blanks
•
2 processor heatsinks
•
1 hot-swap and redundant capable high-efficient 750W
power supply
•
2 chassis front handles in the box (ears)
1
1
1
